Артикул
Название
Примечание
Количество
1
87412687
HANDLE
Loader Control Lever, Two Button; Declutch and Differential Lock Switches; Models Without Powershift Transmission
1шт.
1a
87412695
HANDLE
Loader Control Lever, Three Button; Kick Down, Declutch and Differential Lock Switches; Models With Powershift Transmission; Not Illustrated
1шт.
256347A1
CONNECTOR, ELEC,Male, 4 Cavities
CONNECTOR
1шт.
258616A1
LOCK
1шт.
298176A1
PLUG
Not Used With Ref 1A
1шт.
87301351
ADHESIVE
Permabond Adhesive, F246, 1 ml With No. 5 Initiator
1шт.
2
133615A1
BOOT
1шт.
3
87310126
SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST
No. 10 x 3/4, Stainless Steel; Replaces 140-107 Non-Stainless Steel Screw Used On Some Models
1шт.
4
131-861
SPRING NUT,Tinn, U, #10-24
1шт.
5
132661A1
LEVER
1шт.
6
195615A1
SUPPORT
1шт.
7
614-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
Replaces 614-6016 M6 x 16 Bolt Used On Some Models
3шт.
8
495-11028
WASHER,1/4", SAE
3шт.
9
495-81184
WASHER,21/32" x 1 1/2" x .030"
1шт.
10
176311A1
BELLCRANK
Incl. Ref 11
1шт.
11
108088A1
BUSHING,15.96mm ID x 19.15mm OD x 15mm L
2шт.
12
102761A1
PIN,15.91mm OD x 35mm L
2шт.
13
432-828
COTTER PIN,1/8" x 1 3/4"
2шт.
14
112380A1
BEARING ASSY
Incl Ref 14A
2шт.
14a
465004R91
BEARING ASSY,0.6693" ID x 1.5748" OD x 0.4724"
Not Illustrated
1шт.
15
614-6016
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
1шт.
16
396-41028
WASHER,.281" x 7/8" x .098", HDN
1шт.
18
231-1446
NUT,3/8" - 16, Gr 5
1шт.
19
413-628
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
2шт.
20
496-21041
WASHER,13/32" x 13/16" x .089", HDN
3шт.
21
425-106
NUT,3/8"-16, Cl 5
1шт.
22
425-116
NUT,3/8" - 24, Gr 5
2шт.
25
132931A1
BOOT
Cab Models
2шт.
189109A1
SPRING,Compression, 42mm OD
Boot Retainer; Cab Models
2шт.
27
432-612
COTTER PIN,3/32" x 3/4"
2шт.
28
REF
INSTRUCTION
LOADER CONTROL VALVE, Two Spool; See Figure 08-34 for Two Spool Valve Options
1шт.
29
814-10090
BOLT,Hex, M10 x 1.5 x 90mm, Cl 8.8
2шт.
30
614-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
3шт.
31
396-41028
WASHER,.281" x 7/8" x .098", HDN
3шт.
32
829-1406
NUT,Hex, M6 x 1, Cl 10.9
3шт.
33
87428151
THREADED ROD
Bucket Control Rod; Canopy Units; No Longer Available, For Service Order 87446596 Rod, Ref 33A
1шт.
33a
87446596
THREADED ROD
Bucket Control Rod; Cab Units; Now Services Cab or Canopy Units
1шт.
34
87428152
THREADED ROD
Lift Control Rod; No Longer Used, For Service Order Ref 34A, 87663804 Rod
1шт.
34a
87663804
THREADED ROD
Rod, Threaded, Lift Control
1шт.
35
D149287
PIN,7.9mm OD x 26.72mm L
2шт.
36
814-10110
BOLT,Hex, M10 x 1.5 x 110mm, Cl 8.8
1шт.
37
87417599
SPACER,11mm ID x 22mm OD x 30mm Thk
3шт.
38
87417721
THREADED INSERT,M10 x 1.5-6H x 29 L
M10
3шт.
Выбрано товаров: 45
