Запчасти Case 590SM (08-47) - VALVE SECTION - BACKHOE DIPPER (WITH PILOT CONTROLS) (08) - HYDRAULICS

87447468

HYD VALVE SECTION

Dipper; Incl. Ref 1 - 10

1шт.

1

NSS

NOT SOLD SEPARAT

HOUSING

1шт.

2

NSS

NOT SOLD SEPARAT

SPOOL

1шт.

3

85826345

KIT,Pressure Compensator

Pressure Compensator Kit; Component Parts Not Serviced Separately

1шт.

4

85811938

KIT,Check Valve

Component Parts Not Serviced Separately

2шт.

5

85826344

KIT,Operation

End Cap Kit; Component Parts Not Serviced Separately

1шт.

6

85812116

VALVE PRESSURE RELIE

Pressure Relief Valve; Side B; Some Component Parts Not Serviced Separately; Serviceable Includes 85811933, Ref 8 Kit

1шт.

6a

85826343

VALVE PRESSURE RELIE

Pressure Relief Valve; Side A; Some Component Parts Not Serviced Separately; Serviceable Includes 85811933, Ref 8 Kit

1шт.

7

NSS

NOT SOLD SEPARAT

Cover

4шт.

8

85811933

SEAL KIT,Secondary Valve

Seal Kit Includes (2) O-Rings, (1) Thrust Ring; Component Parts Not Serviced Separately

2шт.

9

85819148

SEAL KIT,Between Control Valve Sections

Seal Kit Includes (6) O-Rings; Component Parts Not Serviced Separately

1шт.

10

85824281

SEAL KIT,Control Valve Section, Complete

Seal Kit Includes (13) O-Rings, (2) Lip Seals; Component Parts Not Serviced Separately

1шт.
