Артикул
Название
Примечание
Количество
1
397132A1
SEAT ASSY.
Standard, Vinyl, Without Armrest, Includes Seat, Pedestal, and Support, See Figures 09-47, 09-48
1шт.
2
397137A1
SEAT ASSY.
Air Suspension, Cloth, Deluxe, With Armrests On Figure 09-51, See Figures 09-51, 09-52
1шт.
2a
397136A2
SEAT ASSY.
Suspension, Cloth, Without Armrests, Includes Seat, Suspension, and Pedestal, See Figures 09-49, 09-50; Replaces 397136A1; Order 397407A1 Service Kit For Seat Assy With Armrests
1шт.
2a
397134A2
SEAT ASSY.
Suspension, Vinyl, Without Armrests, Includes Seat, Suspension, and Pedestal, See Figures 09-49, 09-50; Replaces 397134A1; Order 397408A1 Service Kit For Seat Assy With Armrests
1шт.
2b
292262A1
ARMREST ASSY.
Kit, Left-Hand
1шт.
2c
292263A2
ARMREST ASSY.
Kit, Right-Hand
1шт.
3
604-12030
BOLT,Hex, M12 x 30mm, Cl 8.8
M12 x 30
4шт.
4
248-2373
GROMMET,1/2" ID x 1 1/4" Groove Dia, Str Cut
1шт.
5
896-15012
WASHER,13.5mm ID x 28mm OD x 4mm Thk
13,5 x 28 x 4 mm
4шт.
7
118769A1
SWITCH
Limit Switch
1шт.
8
470-10620
SCREW,Pan HD, #6 - 32 x 1-1/4"
2шт.
9
495-31016
WASHER,#6
2шт.
10
193-1003
NUT,Keps, w/LW,#6-32
2шт.
11
119211A1
BRACKET
Switch Mounting, Suspension Seat
1шт.
11a
186351A1
GUARD
Harness
1шт.
12
87408889
SAFETY BELT ,50.80 mm W
Replaces D150377; If used; Standard Seat Belt Mounting
1шт.
13
87408888
SAFETY BELT ,76.20 mm W
Retractable, Replaces R58418; If used; Standard Seat Belt Mounting
1шт.
14
414-724
BOLT,Hex, 7/16" - 20 x 1-1/2", Gr 5
2шт.
15
D150391
SPACER
2шт.
16
D150392
BRACKET
Left-Hand; Standard Seat Belt Mounting
1шт.
17
495-81169
WASHER,17/32" x 2 1/2" x .120"
Not Used On Deluxe Air Suspension Seat
2шт.
18
496-81010
WASHER
15/32 x 1 x 7/64
4шт.
19
232-4617
LOCK NUT,7/16"-20, GC
2шт.
20
87408889
SAFETY BELT ,50.80 mm W
Replaces D150377; If used; Suspension Seat Belt Mounting
1шт.
21
87408888
SAFETY BELT ,76.20 mm W
Retractable, Replaces R58418; If used; Suspension Seat Belt Mounting
1шт.
22
414-724
BOLT,Hex, 7/16" - 20 x 1-1/2", Gr 5
2шт.
23
D150391
SPACER
2шт.
24
D150392
BRACKET
Left-Hand; Suspension Seat Belt Mounting
1шт.
25
496-81010
WASHER
15/32 x 1 x 7/64
2шт.
26
232-4617
LOCK NUT,7/16"-20, GC
2шт.
Выбрано товаров: 30
