Запчасти Case 590SL (9-72) - DELUXE AIR SUSPENSION SEAT, SEAT, SLIDE AND SWIVEL ASSEMBLY (09) - CHASSIS/ATTACHMENTS

121414A1

FUSE,20A, Mini, Yellow

Not shown

1шт.

614-12030

BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd

4шт.

892-11012

LOCK WASHER,M12

4шт.

275547A1

SEAT ASSY.

SEAT ASSEMBLY - air suspension, cloth, deluxe, complete with armrests, parts list figures 9-72 and 9-73, Includes: Ref. 1 - 25

1шт.

1

300657A1

KIT

- seat top assembly, without armrests, includes seat and backrest cushions, backrest cover and hardware

1шт.

2

300659A1

KIT

- armrest, right-hand, includes armrest knob and shaft, groove pin, pivot stud and screw

1шт.

3

300661A1

KIT

- armrest, left-hand, includes armrest knob and shaft, groove pin, pivot stud and screw

1шт.

4

300662A1

KIT

- seat cushion, with frame, includes seat frame and cushion, (5) Christmas tree clips, (18) hog rings, (1) screw and recliner handle

1шт.

5

300663A1

KIT

- backrest cushion, with frame, includes backrest frame and cushion, (23) hog rings, lumbar, (2) screws and (2) Christmas tree clips

1шт.

6

176091A1

PACKAGE,SERVICE

KIT - retaining, hog ring, package of 48 rings for cushions, not shown

1шт.

7

300664A1

KIT

- backrest cover, cloth, and clips, Includes: Ref. 8

1шт.

8

1999693C1

KIT

CLIP - christmas tree, package of 14

1шт.

9

300665A1

KIT

- lumbar, includes actuator

1шт.

10

300667A1

KNOB

- lumbar knob

1шт.

11

1987212C1

PACKAGE

KIT - seat cushion back tilt knob, includes knob, recliner handle and (1) screw

1шт.

12

300670A1

KIT

- lateral isolator assembly, includes Ref. 13 - 17

1шт.

13

1987219C2

SET OF PARTS

KIT - lateral isolator shock, includes shock absorber, (1) bearing, (2) bushings, (1) nut, (2) washers, (1) spacer and (1) retaining ring

1шт.

14

1987290C1

SET OF PARTS

KIT - spring, lateral isolator, includes (2) springs and (1) bolt

1шт.

15

259054A1

SET OF PARTS

KIT - lateral isolator control, lock, includes latch rod, bracket, (2) bearings, knob and (2) roll pins

1шт.

16

1344025C1

PIVOT PIN

PIN - clevis, pivot

1шт.

17

1344026C1

SPRING

- latch

1шт.

18

300672A1

SWITCH

- rocker, height adjustment

1шт.

300674A1

HARNESS

- swivel switch, not shown

1шт.

19

300675A1

KIT

- slide/swivel assembly, includes Ref. 21

1шт.

20

300680A1

KIT

- slide puck, includes (2) adjustable slider blocks, (2) stationary slider blocks and (2) set screws

1шт.

21

300677A1

KIT

- upper slide plate assembly, includes upper slide plate weldment, slide and swivel levers, (3) springs, (3) roll pins, (3) E-rings and slide latch weldment, Includes: Ref. 22 - 24

1шт.

22

300679A1

SLIDE

- latch weldment

1шт.

23

300681A1

CONTROL LEVER

LEVER - slide control

1шт.

24

300683A1

LEVER

- swivel

1шт.

25

300684A1

SAFETY BELT

SAFETY BELT

1шт.
