Запчасти Case 590SL (9-62) - TILT HOOD, UPRIGHT COVER, GRILLE UNIT, AND CHAFF SCREEN (09) - CHASSIS/ATTACHMENTS

1

139486A2

HOOD

- engine, tilt

1шт.

2

175599A1

LATCH

- hood

1шт.

3

614-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8

10шт.

5

829-1410

NUT,M10 x 1.5, Cl 10.9

8шт.

7

139362A1

BALL JOINT

STUD - upper ball, 10 mm - 1.5, no longer used, order 139363A1 stud, Ref. 9

2шт.

8

114980A1

GAS STRUT

Cylinder spring, Counterbalance, Hood

2шт.

9

139363A1

BALL JOINT,M10 x 1.5mm x 42mm L

STUD - lower ball

2-4шт.

10

F44883

CLIP,DIN 71805 - S10

RETAINER - lock, ball stud retainer

4шт.

11

292785A2

HOOD ASSY.

COVER - chassis upright, with turbocharged engine, if used

1шт.

12

440-11012

SCREW,Cross Pan Hd, #10-24 x 3/4"

- machine, pan Phillips, No. 10 NC x 3/4 inch

2шт.

13

109879A1

SPACER,5.5mm ID x 30mm OD

- plastic, hood spacer

2шт.

14

185325A1

SPACER,5.5mm ID x 30mm OD x 2mm L

WASHER - spacer

4шт.

15

86625057

NUT,#10-24, GB

NUT, LOCK, #10-24, GB

2шт.

16

614-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8

If Used Hex, M10 x 25, 8.8, Full Thd

4шт.

16

614-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd

- hex, full threads, 10 - 1.5 x 35 mm, if used, used on models with J-nuts on chassis uprights

4шт.

18

121856A1

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9

BOLT - hex washer, special, 10 - 1.5 x 30 mm

8шт.

19

825-2410

FLANGE NUT,M10 x 1.5, Flg, Cl 8

- hex flange, 10 mm - 1.5

4шт.

20

139502A1

PROTECTOR

BUMPER - grille, left-hand upper

1шт.

21

244287A1

PROTECTOR

BUMPER - grille, left-hand lower

1шт.

22

139500A1

PROTECTOR

BUMPER - grille, right-hand upper

1шт.

23

244286A1

PROTECTOR

BUMPER - grille, right-hand lower

1шт.

24

229398A2

SIEVE

GRILLE - radiator shroud, see page 9-155 for Case emblem

1шт.

25

233262A1

SEALING STRIP,20mm W x 596mm L x 6mm Thk

- foam, adhesive-backed, 20 (25/32) x 596 (23-15/32) x 6 mm (1/4 inch), with or without air conditioning, if used

1шт.

26

253889A1

SCREEN

- chaff

1шт.

27

255447A1

THREADED INSERT

INSERT, THREADED, 1/4", if used

10шт.

28

257381A1

BOLT

BOLT - hex, 1/4 NC x 3/4 inch, if used

8шт.

29

257382A1

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

- flat, 1/4 inch, if used

8шт.

30

255687A1

RIVET

INSERT - threaded, No. 10, if used

10шт.

31

140-107

SCREW,Pan HD, #10 - 24 x 3/4"

If used Cross Pan Hd, #10-24 x 3/4"

8шт.

32

185325A1

SPACER,5.5mm ID x 30mm OD x 2mm L

WASHER - spacer, flat, No. 10, if used

8шт.

33

187389A1

LARGE PLATE

PANEL - noise reduction, insulation

1шт.

34

353-402

PLUG,Dome, .375" hole, Nylon

Models without windshield washer, If used Dome, .375" hole, Nylon

1шт.

35

234923A1

PROTECTOR

TRIM - 150 mm (5-29/32 inch) long, hood, if used

2шт.

36

246228A1

TRIM,1040mm L

TRIM - 1040 mm (41 inch) long, hood, if used

2шт.

37

329994A1

HOOD ASSY.

COVER - chassis upright, with turbocharged engine, if used

1шт.

4

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

- flat, 11 x 20 x 2 mm

14шт.

6

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

- flat, 11 x 20 x 2 mm

2шт.

17

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

- flat, 11 x 20 x 2 mm

4шт.
