Артикул
Название
Примечание
Количество
1
122974A1
LATCH
Backhoe boom
1шт.
3
D129227
PIN,40mm OD x 196mm L
- Boom latch to swing tower, Replaces 175814A1
1шт.
4
D144592
WASHER,41mm ID
- flat, special
2шт.
5
800-44040
SNAP RING,M40, Ext
RING - heavy external retaining, No. 40, pin retaining
2шт.
6
D129641
CABLE
- latch control, replaces D146241 cable
1шт.
7
614-10025
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
2шт.
8
D143417
SPACER,10.31mm ID x 15.88mm OD x 6.4mm L
- 10 ID x 16 OD x 6 mm long
1шт.
9
185632A2
THREADED ROD
ROD - boom latch control
1шт.
10
D143723
SHIN
CLAMP - rod
2шт.
12
892-11010
LOCK WASHER,M10
3шт.
13
122958A1
SQUARE NUT
- square, special, 10 mm - 1.5
1шт.
14
D143591
RING, SNAP,12.7mm ID, Ext
RETAINER - clip ring
4шт.
15
D86664
BOOT
- rod
1шт.
16
102924A1
BUMPER
- boom
1шт.
17
D143735
CLAMP,19.1mm - 22.2mm
- boot
1шт.
18
614-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
Full Thd, No longer included with boom, If used Hex, M10 x 30, 8.8
1шт.
18
814-10055
BOLT,Hex, M10 x 1.5 x 55mm, Cl 8.8
- hex, 10 - 1.5 x 55 mm, If used
1шт.
21
829-1410
NUT,M10 x 1.5, Cl 10.9
1шт.
22
896-11012
WASHER,13.5mm ID x 24mm OD x 3mm Thk
1шт.
23
832-10410
NUT,M10 x 1.5, Cl 8
NUT, LOCK, , If used M10 x 1.5, Cl 8
1шт.
24
221461A1
SPACER
- boom latch
1шт.
25
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
1шт.
20
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
- flat, 11 x 20 x 2 mm
3шт.
Выбрано товаров: 23
