Артикул
Название
Примечание
Количество
129264A1
RADIATOR
ASSEMBLY - engine coolant, 4 row, no longer available, order 234876A1 radiator, Includes: Ref. 1 - 9
1шт.
1
175161A1
TANK
TANK - upper
1шт.
2
181148A1
CORE
CORE - radiator, 4 row
1шт.
4
175162A1
RESERVOIR
TANK - lower
1шт.
5
175164A1
SUPPORT
BRACKET - left-hand, radiator
1шт.
6
175165A1
SUPPORT
BRACKET - right-hand, radiator
1шт.
7
614-8012
BOLT,Hex, M8 x 1.25 x 12mm, Cl 8.8, Full Thd
- hex, full threads, 8 - 1.25 x 12 mm
8шт.
8
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
- flat, 9 x 17 x 1.6 mm
8шт.
9
A170241
RADIATOR CAP
CAP, RADIATOR, Filler, 15 psi
1шт.
234876A1
RADIATOR
ASSEMBLY - engine coolant, 4 row, if used, used with 139783A1 or 231280A1 oil cooler, see Figure 6-20 for cooler, Includes: Ref. 1 - 10
1шт.
1
175161A1
TANK
TANK - upper
1шт.
2
181148A1
CORE
CORE - radiator, 4 row
1шт.
4
175162A1
RESERVOIR
TANK - lower
1шт.
5
175164A1
SUPPORT
BRACKET - left-hand, radiator
1шт.
6
175165A1
SUPPORT
BRACKET - right-hand, radiator
1шт.
7
614-8012
BOLT,Hex, M8 x 1.25 x 12mm, Cl 8.8, Full Thd
- hex, full threads, 8 - 1.25 x 12 mm
8шт.
8
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
- flat, 9 x 17 x 1.6 mm
8шт.
9
A170241
RADIATOR CAP
CAP, RADIATOR, Filler, 15 psi
1шт.
10
NSS
NOT SOLD SEPARAT
SEAL - foam, side channel brackets, not shown
2шт.
239739A1
RADIATOR
ASSEMBLY - engine coolant, heavy duty, 5 row, if used, used with 235811A1 heavy duty oil cooler, see Figure 6-21A for cooler, Includes: Ref. 1 - 11
1шт.
1
175161A1
TANK
TANK - upper
1шт.
2
257434A1
CORE
CORE - radiator, 5 row
1шт.
4
175162A1
RESERVOIR
TANK - lower
1шт.
5
175164A1
SUPPORT
BRACKET - left-hand, radiator
1шт.
6
175165A1
SUPPORT
BRACKET - right-hand, radiator
1шт.
7
614-8012
BOLT,Hex, M8 x 1.25 x 12mm, Cl 8.8, Full Thd
- hex, full threads, 8 - 1.25 x 12 mm
8шт.
8
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
- flat, 9 x 17 x 1.6 mm
8шт.
9
A170241
RADIATOR CAP
CAP, RADIATOR, Filler, 15 psi
1шт.
10
NSS
NOT SOLD SEPARAT
SEAL - foam, side channel brackets, not shown
2шт.
11
NSS
NOT SOLD SEPARAT
SEAL - foam, corners, side channel brackets, not shown
4шт.
Выбрано товаров: 33
