Запчасти Case 580SD (604) - DECALS (09) - CHASSIS/ATTACHMENTS

N7013

DECAL

KIT - decal, 580D, Includes: Ref. 31A - 51A

1шт.

31a

321-6398

DECAL

- Caution, brake fluid

1шт.

31b

321-6452

DECAL

- operators manual location, tool box

1шт.

31c

D123080

DECAL - Attention, operating turbocharged engines, Super D models only, not included in kit, must be ordered separately

1шт.

32

321-3718

DECAL

- loader control pattern

1шт.

33

321-6413

DECAL

- Warning, left-hand loader lift arm support strut usage, replaces 321-4408 decal

1шт.

33a

321-3581

DECAL

- auxiliary hydraulics, loader control pattern

1шт.

34

321-1708

DECAL

- clam bucket opening

1шт.

35

321-1707

DECAL

- clam bucket position

1шт.

36

321-5506

DECAL

- Case, with treads, rear, black, if used

1шт.

36

321-6402

DECAL

- Case, with treads, rear, yellow, if used

1шт.

36a

D120621

DECAL

- Case, with treads, rear, white color for use on dark painted tractors, not included in kit, must be ordered separately, not shown

1шт.

37

321-4481

DECAL

- Warning, swinging boom

2шт.

38

321-5571

DECAL

- backhoe control pattern, two lever

1шт.

39

321-5569

DECAL

- standard backhoe control pattern, upper

1шт.

40

321-5568

DECAL

- standard backhoe control pattern, lower

1шт.

41

321-3056

DECAL

- Caution, transport

1шт.

42

321-3058

DECAL

- Important, swinging boom

1шт.

43

321-5572

DECAL

- extendahoe control pattern, upper

1шт.

44

321-5573

DECAL

- extendahoe control pattern, lower

1шт.

45

321-3139

DECAL

- extendahoe

2шт.

45a

D120625

DECAL

- extendahoe, white color for use on dark painted tractors, not included in kit, must be ordered separately, not shown

1шт.

46

321-6251

DECAL

- 580D, on extendable dipper housing

2шт.

47

321-5595

DECAL

- Extendahoe, pedal control pattern

1шт.

48

321-6046

WARNING DECAL

DECAL, WARNING, Backhoe load

1шт.

49

321-5361

KIT

DECAL - Case, three-point hitch frame

2шт.

50

321-6058

DECAL

- three-point hitch control pattern, single spool models

1шт.

51

321-6059

DECAL

- three-point hitch control pattern, four spool models

1шт.

51a

321-3775

DECAL

- Caution, pallet fork, self-leveling

1шт.
