Запчасти Case 580SD (572) - CAB HEADLINER AND WINDSHIELD WIPER COVERS (09) - CHASSIS/ATTACHMENTS

1

F45200

COVER ASSY

HEADLINER - cab models without blower, air conditioning, and/or heater, if used

1шт.

2

F41978

JOURNAL

HEADLINER - front, models with blower, air conditioning, and/or heater, with ball-type louvers, no longer used, order F45202 headliner (Ref. 5) and (3) F89948 slat-type louvers (Ref. 8)

1шт.

3

F64132

GUARD

LOUVER - ball-type, if used

6шт.

4

F64131

RING

RETAINING RING - louver, if used

6шт.

5

F45202

PLATE

HEADLINER - front, models with blower, air conditioning, and/or heater, slat-type louvers

1шт.

6

F41797

HEADLINER - rear, models with blower, air conditioning, and/or heater, with one slat-type louver, not shown, no longer available, order F45201 headliner (Ref. 7) and (1) F89948 louver (Ref. 8)

1шт.

7

F45201

LINING

HEADLINER - rear, models with blower, air conditioning, and/or heater, used with two slat-type louvers

1шт.

8

F89948

GUARD

LOUVER - slat-type

1-5шт.

9

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

SCREW - self-tapping, Phillips head, with washer, No. 10 - 16 NC x 3/4", interchangeable with Refs. 10 and 11

18шт.

10

187-1084

SELF-TAP SCREW,Cross Oval Hd, #10 x 3/4"

SCREW - self-tapping, Phillips head, No. 10 - 16 NC x 3/4", plated, if used

18-34шт.

11

F63765

WASHER

- shoulder, special, if used

18-34шт.

12

F42918

COVER

- rear windshield wiper, front

1шт.

13

187-1098

SELF-TAP SCREW,Cross Oval Hd, #10 x 3/4"

SCREW - self-tapping, Phillips head, No. 10 - 16 NC x 3/4", plated, if used

8шт.

14

F64315

WASHER

- special, if used

8шт.

15

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

SCREW - self-tapping, Phillips head, with washer, No. 10 - 16 NC x 3/4", interchangeable with Refs. 13 and 14

8шт.

16

F42781

COVER

- rear windshield wiper

1шт.

17

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

- 1/4" - 20 NC x 5/8", plated

3шт.

18

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, 1/4"

3шт.

19

7770

NUT,Hex, 1/4 - 20, Cl 5

1/4"-20, G5

3шт.

20

F42837

BRACKET

- cover mounting, straight

2шт.

21

F41977

BRACKET

- cover mounting, bent

1шт.

22

F42836

BRACKET

- wiper cover support

1шт.

23

131-861

SPRING NUT,Tinn, U, #10-24

1шт.

24

182-540

SCREW,Sl Pan Hd, 1/4" - 20 x 3/8"

MACHINE SCREW - 1/4" - 20 NC x 3/8", plated, used without rear windshield wiper, if used

3шт.

25

129-723

RETAINER

- headliner, used without rear windshield wiper, if used

3шт.

26

131-1280

JAM NUT,Jam, 1/4"-20

NUT - hex, jam, 1/4" - 20 NC, plated, used without rear windshield wiper, if used

3шт.
