(88.100.35[48]) - DIA KIT, DIPPER OSCILLATION

Запчасти Case 580N EP (88.100.35[48]) - DIA KIT, DIPPER OSCILLATION (88) - ACCESSORIES

Схема запчастей Case 580N EP - (88.100.35[48]) - DIA KIT, DIPPER OSCILLATION (88) - ACCESSORIES
35.359.ab (18)
1
7
10
10
4
3
6
2
10
9
5
8
35.359.ab (19)
35.359.ab (21)
35.359.ab (20)
35.359.ab (23)
35.359.ab (22)
35.359.ab (17)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47593980

CONSTRUCTION DIA

Kit, Dipper Oscillation, Incl 2 - 10

1шт.

2

84551838

CONTROL VALVE

Backhoe 6 Spool Pilot Control, ASSY, Incl 3 - 10

1шт.

3

84278712

HYD VALVE SECTION

Inlet, ASSY

1шт.

4

84586031

HYD VALVE SECTION

Swing, ASSY

1шт.

5

84278714

HYD VALVE SECTION

Boom, ASSY

1шт.

5

84278714R

REMAN-HYD VALVE

Reman Valve - Boom

1шт.

5

84278714C

CORE-VALVE HYD

Core Return Number

1шт.

6

84157939

HYD VALVE SECTION

Stabilizer, ASSY

2шт.

7

84278710

HYD VALVE SECTION

Dipper, ASSY

1шт.

8

84278702

HYD VALVE SECTION

Bucket, ASSY

1шт.

9

85811915

HYD VALVE SECTION

Outlet, ASSY

1шт.

10

85811958

KIT

Backhoe 6 Spool Valve Tie Rods

1шт.
