Запчасти Case 580N EP (88.100.35[46]) - DIA KIT, DIPPER OSCILLATION (88) - ACCESSORIES

1

47593980

CONSTRUCTION DIA

Kit, Dipper Oscillation, Incl 2 - 19

1шт.

2

87685956

JOYSTICK

RH, ASSY

1шт.

3

87308839

HANDLE GRIP

1шт.

4

87308838

HANDLE GRIP

1шт.

5

87443721

BOOT

1шт.

6

87547309

BEZEL

1шт.

7

87435506

SEAL,52mmL

2шт.

8

87424267

GROMMET

1шт.

9

87428023

BOLT,Square Head, M12 x 1.75 x 60

1шт.

10

87037944

THIN NUT,Thin, M12 x 1.75, Cl 05

1шт.

11

87436225

RETAINER,12.5mm ID, 46mm OD

1шт.

12

15687475

SELF-TAP SCREW,Pan Hd, M3.5 x 25mm, SST

3шт.

13

86625128

PLUG,Dome, .562" hole, Nylon

2шт.

14

87000312

CABLE TIE,4.8mm W x 203.2mm OAL, Nylon

1шт.

15

87438046

CABLE TIE,375.9 mm L x 8mm W

1шт.

16

87687141

PILOT VALVE

ASSY

1шт.

16

87687141R

REMAN-HYD VALVE

Reman Assy

1шт.

16

87687141C

CORE-VALVE HYD

Core Return Number

1шт.

17

87546922

SWITCH ASSY

Push Button ODT

1шт.

18

225315C1

ELEC CONNECTOR,Male, 2 Pin

1шт.

19

225318C1

ELEC CONNECTOR,2 Pin

1шт.
