(88.100.35[12]) - DIA KIT, NO AUX TO COMBO, STD, PC

Запчасти Case 580N EP (88.100.35[12]) - DIA KIT, NO AUX TO COMBO, STD, PC (88) - ACCESSORIES

Схема запчастей Case 580N EP - (88.100.35[12]) - DIA KIT, NO AUX TO COMBO, STD, PC (88) - ACCESSORIES
35.359.ab (18)
8
4
2
3
6
5
9
11
1
7
10
11
35.359.ab (24)
35.359.ab (19)
35.359.ab (21)
35.359.ab (20)
35.359.ab (23)
35.359.ab (22)
35.359.ab (17)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47501545

CONSTRUCTION DIA

No Auxiliary to Combo, Standard Dipper, Pilot Control, Incl 9, 11

1шт.

2

84551842

CONTROL VALVE

Backhoe 7 Spool pilot Control, ASSY, Incl 3 - 11

1шт.

3

84278712

HYD VALVE SECTION

Inlet, ASSY

1шт.

4

84586031

HYD VALVE SECTION

Swing, ASSY

1шт.

5

84278714

HYD VALVE SECTION

Boom, ASSY

1шт.

5

84278714R

REMAN-HYD VALVE

Reman Valve - Boom

1шт.

5

84278714C

CORE-VALVE HYD

Core Return Number

1шт.

6

84157939

HYD VALVE SECTION

Stabilizer ASSY

2шт.

7

84278710

HYD VALVE SECTION

Dipper, ASSY

1шт.

8

84278702

HYD VALVE SECTION

Bucket, ASSY

1шт.

9

84278691

HYD VALVE SECTION

BI-DIR Pilot, ASSY

1шт.

10

85811915

HYD VALVE SECTION

Outlet, ASSY

1шт.

11

87751102

BOLT

3шт.
