Запчасти Case 580N EP (35.300.AQ[02]) - HYDRAULIC OIL RESERVOIR (35) - HYDRAULIC SYSTEMS

Схема запчастей Case 580N EP - (35.300.AQ[02]) - HYDRAULIC OIL RESERVOIR (35) - HYDRAULIC SYSTEMS
9
2
12
35.300.be
16
8
35.300.aq (01)
1
14
39.100.ab (03)
5
13
39.100.ab (01)
6
7
4
3
15
39.100.ab (02)
10
11

Артикул

Название

Примечание

Количество

1

84298013

CAP,128.8mm D

Hydraulic

1шт.

2

86625195

SCREW,Pan Head, #6 - 32 x 5/8"

2шт.

3

47713922

FILTER STRAINER

1шт.

4

226456A1

LEVEL GAUGE

ASSY, Incl 5, 6

1шт.

5

238-6114

O-RING,0.103" Thk x 0.612" ID, -114, Cl 6, 90 Duro

4шт.

6

NSS

NOT SOLD SEPARAT

Liquid Level Gauge, Incl in 4

1шт.

7

87673270

ADHESIVE STRIP

1шт.

8

84281665

COVER

Battery

1шт.

9

87694065

ANTI-SKID STRIP

Tool Box

1шт.

10

120103

BOLT,M8 x 1.25 x 16mm, Cl 8.8

4шт.

11

87655042

SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk

4шт.

12

47447702

STRIP

1шт.

13

218-5155

PLUG,9/16" - 18 ORB

ASSY, Incl 14, 15

1шт.

14

NSS

NOT SOLD SEPARAT

Plug, Incl in 13

1шт.

15

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

16

218-5158

PLUG,Hex Hd, 1 1/16"-12 ORB

1шт.

Выбрано товаров: 16
