Запчасти Case 580N EP (25.100.AD) - FRONT AXLE, HOUSING, 4WD (25) - FRONT AXLE SYSTEM

1

87748946

BUSHING,50.21mm ID x 60.03mm OD x 54mm L

2шт.

2

D123655

SEAL,50mm ID x 60.15mm OD x 4.06mm Thk

Pin Rod End

2шт.

3

84258517

BREATHER,M10 x 1

M10 x 1

1шт.

4

84497932

AXLE HOUSING

1шт.

5

84241623

SPRING,Belleville, 36.13mm ID x 70.85mm OD x 2.26mm Thk

2шт.

6

84529088

BUSHING,35mm ID x 46.99mm OD x 18.45mm W

2шт.

7

84522998

BRONZE BUSHING,30mm ID x 34mm OD x 30mm L

Steel Back

2шт.

8

47601946

OIL SEAL,30mm ID x 44mm OD x 17mm Thk

2шт.

9

84528985

BEARING ASSY,24.99mm ID x 46.99mm OD x 14.77mm W

2шт.

10

84529094

SPRING,42.6mm ID x 60.85mm OD x 1mm Thk

2шт.

11

4985062

DOWEL,15mm OD x 25mm L

Pin, Clutch housing Axle Casting

2шт.

12

14326211

PLUG,M22 x 1.50, R50, ZND

2шт.

13

87015541

BOLT,Hex, M12 x 70, 10.9

4шт.

14

47486257

BUSHING,12mm ID x 15mm OD x 25mm L

4шт.

15

NSS

NOT SOLD SEPARAT

Cover, Differential, Incl in 16

1шт.

16

84527674

COVER ASSY

ASSY, Incl 13 - 15

1шт.

17

47723589

SERRATED BOLT,Hex Flg, M12 x 1.75 x 33mm, Cl 12.9, Full Thd

10шт.
