(23.314.AI) - REAR AXLE, HALF SHAFT

Запчасти Case 580N EP (23.314.AI) - REAR AXLE, HALF SHAFT (23) - FOUR WHEEL DRIVE SYSTEM

Схема запчастей Case 580N EP - (23.314.AI) - REAR AXLE, HALF SHAFT (23) - FOUR WHEEL DRIVE SYSTEM
21.112.ac (01)
2
3
1
3
3
2
2
2
3
27.100.ak
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47566698

DRIVE SHAFT,320mm L

Rear

1шт.

2

D137626

CLAMP,30.175mm D Clamping Pipe

Driveshaft Spider Bearing

4шт.

3

9637611

SCREW,Hex Flng, 5/16" - 24 x 3/4"

8шт.

Выбрано товаров: 3
