Артикул
Название
Примечание
Количество
REF
INSTRUCTION
MODELS WITHOUT PILOT CONTROLS
1шт.
1
87480653
DAMPING VALVE
Swing Cushion; See Figure 08-55; ; Replaces 87449373
1шт.
2
87428140
BRACKET, SUPPORTING
Valve Bracket
1шт.
3
814-10040
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
2шт.
4
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
4шт.
5
829-1410
NUT,M10 x 1.5, Cl 10.9
2шт.
6
614-18035
BOLT,Hex, M18 x 2.5 x 35mm, Cl 8.8, Full Thd
2шт.
7
895-11018
WASHER,M18 x 34 x 3
4шт.
8
218-5062
HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring
Incl. Ref 9
4шт.
9
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
10
87423356
HOSE ASSY.,12.7mm ID x 850mm L
850 mm (33-1/2 in)
1шт.
11
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
Incl. Ref 12
2шт.
12
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
Boss seal
1шт.
13
188027A2
CYLINDER ASSY.,Double Acting, 50.8mm Rod, 292mm Stroke
95 ID x 292 mm strk; Swing Cylinder, See Figure 08-62
2шт.
188027A2R
REMAN-HYD CYLINDER
580M (SERIES 2) (TIER 2) (NA) (2/08-)
2шт.
188027A2C
CORE-HYD CYLINDER
Return Number
1шт.
14
87423356
HOSE ASSY.,12.7mm ID x 850mm L
850 mm (33-1/2 in)
1шт.
15
192971A1
ORIFICE,9.52mm OD x 7.14mm ID, 3.18mm x 6 ID, 3.61mm ID
Restrictor
2шт.
19
218-5119
ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 1-1/16" - 12 Male ORB
Incl. Ref 20
2шт.
20
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
Boss Seal
1шт.
22
214-1492
HOSE CLAMP,#92, 5.38" - 6.25", Type F Worm
2шт.
23
87441076
HYDRAULIC HOSE,9.53mm ID x 802mm L
802 mm (31-19/32 in)
2шт.
24
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
Incl. Ref 25
2шт.
25
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
Boss seal
1шт.
26
87428158
HOSE ASSY.
1194 mm (47 in)
2шт.
27
218-5107
90 ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB
Incl. Ref 28
2шт.
28
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
29
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP
1шт.
Выбрано товаров: 29
