Артикул
Название
Примечание
Количество
1
87430972
HYDRAULIC HOSE,19.05mm ID x 2467mm L
2467 mm (97-1/8 in); Models With Uni-Directional
1шт.
2
87429387
HYDRAULIC HOSE,19.05mm ID x 2890mm L
2890 mm (113-13/16 in); Models With Uni-Directional
1шт.
3
87431630
BRACKET
2шт.
4
329799A1
SUPPORT
LH
1шт.
5
329797A1
SUPPORT
RH
1шт.
6
604-20045
BOLT,Hex, M20 x 45mm, Cl 8.8
2шт.
7
144477A1
ISOLATOR
2шт.
8
144479A1
CLAMP
2шт.
9
413778A1
BRACKET
45 degree Bend
1-2шт.
9a
282842A1
BRACKET
90 degree Bend
1шт.
10
614-10040
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
2шт.
11
614-10025
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
2шт.
12
892-11010
LOCK WASHER,M10
4шт.
13
829-1410
NUT,M10 x 1.5, Cl 10.9
4шт.
14
144477A1
ISOLATOR
2шт.
15
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP
1шт.
16
87440694
BRACKET
1шт.
17
814-12050
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
2шт.
18
896-11012
WASHER,13.5mm ID x 24mm OD x 3mm Thk
4шт.
19
829-1412
NUT,M12, Cl 10.9
2шт.
20
87421836
HYDRAULIC VALVE
See Fig. 08-23B, Serial Range: -N6C412133
1шт.
20
87448993
HYDRAULIC VALVE
Auxiliary Hammer Uni-Directional; See Figure 08-23C, Start Serial: N6C412134
1шт.
21
814-8070
BOLT,Hex, M8 x 1.25 x 70mm, Cl 8.8
2шт.
22
892-11008
LOCK WASHER,8mm ID
2шт.
23
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
2шт.
24
218-980
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw
2шт.
25
218-5057
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
Incl. Ref 26
2шт.
26
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
27
218-5064
HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB
Incl. Ref 28
4шт.
28
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
29
218-5231
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
2шт.
30
218-335
CAP,37 Degree, 1 1/16"-12
2шт.
31
218-5351
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
Incl. Ref 32; If Used
1шт.
32
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
33
218-5230
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
1шт.
34
218-5216
TEE,37 Degree, 1 1/16"-12x1 1/16"-12, Fem Sw Runx1 1/16"-12
1шт.
35
218-5158
PLUG,Hex Hd, 1 1/16"-12 ORB
Incl. Ref 36
1шт.
36
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
37
87455832
HYDRAULIC HOSE,19.05mm ID x 1020mm L
1020 mm (40-3/16 in); Loader Valve to Backhoe Valve; Power Beyond
1шт.
38
87518479
HYDRAULIC HOSE
770 mm (30-11/32 in); 'E' Port Auxiliary Hammer Uni-Directional Valve to Backhoe Valve
1шт.
39
87443052
HYDRAULIC HOSE
715 mm (28-5/32 in); 'LS' Port Auxiliary Hammer Uni-Direction Valve to Backhoe Valve
1шт.
40
87423969
HYDRAULIC HOSE,19.05mm ID x 1500mm L
1500 mm (59-1/16 in); Models With Bi-Directional
1шт.
41
87423970
HYDRAULIC HOSE,19.05mm ID x 1725mm L
1725 mm (67-15/16 in); Models With Bi Directional
1шт.
42
218-5064
HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB
Incl. Ref 43
2шт.
43
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
44
87445794
HYDRAULIC HOSE
375 mm (14-13/16 in)
1шт.
45
218-5222
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
1шт.
Выбрано товаров: 47
