Запчасти Case 480CK (082) - TORQUE TUBE

1

A37976

TUBE - torque

1шт.

2

A35216

COVER

- timing hole

1шт.

3

138-65

LOCK PIN,1/8" x 1 1/2", Slotted

PIN, , Timing pointer 1/8" x 1 1/2", Slotted

1шт.

4

A37789

CAP

COVER - front (w/no hydraulics)

1шт.

5

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

11шт.

6

92-6

LOCK WASHER,3/8"

11шт.

7

G10876

GASKET

- front cover

1шт.

8

A38315

PLUG

- front cover (Replaces G10349)

1шт.

9

A38660

GASKET

- cover plug (Nylon) (Replaces G10351)

1шт.

10

A39029

GASKET

- torque tube to transmission (Replaces A37218)

1шт.

11

A37992

STUD

- tube to trans. (1/2" N.C./N.F. x 2-3/8")

1шт.

12

A29336

STUD

- tube to trans. (1/2" N.C./N.F. x 2-1/2")

2шт.

13

A37993

X

STUD - tube to trans. (1/2" N.C./N.F. x 2-7/16")

1шт.

14

A29540

PIN

DOWEL -, Serial Range: tube-trans

2шт.

15

25-118

NUT,1/2"-20, G5

- 1/2" N.F. hex

4шт.

16

92-8

LOCK WASHER,1/2"

4шт.

20

A7082

COVER

- hand hole

1шт.

21

13-68

SCREW,Hex, 3/8" - 16 x 1/2", Gr 5

BOLT - 3/8 x 1/2" N.C. hex. hd.

1шт.

22

92-6

LOCK WASHER,3/8"

1шт.

23

A35842

COVER

- flywheel (Used w/stamped oil pan only)

1шт.

24

13-1012

BOLT,Hex, 5/8" - 11 x 3/4", Gr 5, Full Thd

2шт.

25

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

26

A14280

PLUG

- drain, torque tube

1шт.

27

A58608

GASKET

- drain plug

1шт.

28

41-1010

PLUG,Cup, 5/8"

- locating hole (3/8" cup type)

1шт.
