Артикул
Название
Примечание
Количество
1
A37406
DIPSTICK
ASSY. - engine oil level, Includes: Ref. 2
1шт.
2
F62075
O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro
"O" RING - dipstick seal (3/4 x 1 x 1/8")
2шт.
3
A37149
TUBE
- oil filler & dipstick (In block)
1шт.
4
A37407
TUBE
EXTENSION - filler & dipstick tube
1шт.
5
214-256
HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm
CLAMP - extension, 1-3/16" to 1-3/4"
1шт.
6
A27342
O-RING,1.109" ID x 1.387" OD x 0.139"
"O" RING - extension to tube (1-1/8 x 1-3/8 x 1/8")
1шт.
7
A37189
FILTER, ELEMENT
FILTER - engine oil
1шт.
8
A153552
ADAPTER
-, Serial Range: filter-block
1шт.
9
41-1016
PLUG,Cup, 1"
- adapter opening (1" cup type)
1шт.
15
G37070
X
PUMP ASSY. - oil, engine (See inset A), Includes: Ref. 16 - 26
1шт.
16
A155144
VALVE, PRESSURE RELI
- relief
1шт.
17
G48500
SPRING
- relief valve
1шт.
18
A29260
RETAINER
- relief spring
1шт.
19
138-62
LOCK PIN,1/8" x 1 1/8", Slotted
PIN, 1/8" x 1 1/8", Slotted
1шт.
20
41-102
PLUG,Exp, 1/2"
- pump body
1шт.
21
G46852
GASKET
- pump cover
1шт.
22
NSS
NOT SOLD SEPARAT
COVER - pump body
1шт.
23
13-420
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
1шт.
23
13-412
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
3шт.
24
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
4шт.
25
73-410
SCREW,Slotted Flat Hd, 1/4"-20 x 5/8"
- mach., 1/4 x 5/8" flat hd
2шт.
26
193-52
LOCK WASHER,Ext Csk Tooth, 1/4"
WASHER, LOCK, Ext Csk Tooth, 1/4"
2шт.
27
A27365
O-RING,0.103" Thk x 0.75" ID, -116, Cl 5, 75 Duro
"O" RING - oil port (3/4 x 15/16 x 3/32")
1шт.
28
G11337
SHIM,.002" Thk
Pump to block .002" Thk
1шт.
28
G11338
SHIM,.005" Thk
Pump to block .005" Thk
1шт.
29
G45766
PIPE, EXHAUST SYSTEM
PIPE - suction
1шт.
30
223-207
LOCK NUT
NUT - lock, pipe to pump, 3/8"
1шт.
31
A30126
FLOAT ASSY. (Includes screen)
1шт.
32
132-50
COTTER PIN,1/8" x 1 1/4"
Pin, Split (Cotter), 1/8" x 1 1/4"
1шт.
A36720
X
PAN ASSY. - oil, engine (Stamped) (Order components), Includes: Ref. 40 - 42
1шт.
40
A36721
CASE
PAN - oil
1шт.
41
A14280
PLUG
- drain
1шт.
42
A58608
GASKET
- drain plug (Nylon) (Replaces A27927)
1шт.
43
193-514
SCREW,SEMS, Hex Hd, 5/16"-18 x 3/4"
BOLT - oil pan (Includes lockwasher)
14шт.
44
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
2шт.
45
195-400
WASHER
- sealing
2шт.
46
G11372
STRIP
- reinforcing
1шт.
47
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
2шт.
48
193-29
LOCK WASHER,Int Tooth, 5/16"
WASHER, LOCK, Int Tooth, 5/16"
2шт.
49
NSS
NOT SOLD SEPARAT
GASKET - oil pan (Order from Page 20)
1шт.
Выбрано товаров: 40
