Запчасти Case 420B (188) - BASIC BACKHOE HYDRAULICS, (WITHOUT EQUALIZER TUBES)

1

D25370

PUMP - hydraulic (See Figure 186 for breakdown)

1шт.

D24447

PUMP - hydraulic (See Figure 184 for breakdown) Use D25370

1шт.

2

D20440

TUBE - backhoe to loader control valve, rear section

1шт.

3

218-486

ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 3/4" - 14 Male NPTF

- 90 degree male (3/4 JIC x 3/4 NPT)

1шт.

4

D20436

TUBE - pump to backhoe, rear section

1шт.

5

D20438

BRACKET - tube mounting, rear

1шт.

6

D20045

PLATE ASSY.

CLAMP - tube

3шт.

7

14-528

BOLT,Hex, 5/16" - 24 x 1-3/4", Gr 5

2шт.

8

92-5

LOCK WASHER,5/16"

WASHER - med. sect. lock, 5/16"

2шт.

9

25-115

NUT,5/16"-24, G5

- hex (5/16"-24 NF)

2шт.

10

36232

HOSE ASSY.

HOSE - backhoe attaching (3/4" I.D. x 1-5/32" O.D. x 32")

1шт.

11

221-330

COUPLING - pipe (3/4 NPT) Not required with quick disconnects

1шт.

35146

DISCONNECT - quick (Not used on some models), Includes: Ref. 12 and 13

2шт.

12

36262

DISCONNECT - quick (Male half)

1шт.

13

36263

DISCONNECT - quick (Female half)

1шт.

14

D21243

TUBE - pump to backhoe, front section

1шт.

15

49789

CLAMP

- tube

3шт.

16

14-48

BOLT,Hex, 1/4" - 28 x 1/2", Gr 5

3шт.

17

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

3шт.

18

D20994

HOSE - pump outlet (3/4" I.D. x 1-5/32" O.D. x 11-1/2"

1шт.

19

D20996

HOSE - left hand reservoir to pump (1" I.D. x 1-1/2" O.D. x 11")

1шт.

20

49766

AUGER

CLAMP - hose

2шт.

21

D21213

TUBE - front to back of left hand reservoir

1шт.

22

218-488

ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1" - 11-1/2 Male NPTF

- 90 degrees male (1 JIC x 1 NPT)

1шт.

23

49782

CLAMP - tube

2шт.

24

14-48

BOLT,Hex, 1/4" - 28 x 1/2", Gr 5

2шт.

25

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

26

18987

TUBE - hydraulic pump, inlet

1шт.

27

D20444

HOSE - connects reservoirs (1" I.D. x 1-1/2" O.D. x 28-1/2")

2шт.

28

214-1420

HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm

CLAMP - hose

2шт.
