Запчасти Case 380CK (006) - CYLINDER BLOCK AND COVERS

1

K961965

CYLINDER

BLOCK - cylinder (Includes sealing rings and bearing caps)

1шт.

2

K914346

RING

- sealing, standard bore

3шт.

2

K917824

RING

- sealing, .020" oversize bore

3шт.

2

K917825

RING

- sealing, .040" oversize bore

3шт.

3

K909564

STEP BOLT

HHCS - 9/16" - 12 NC x 3-15/16", main bearing caps

8шт.

K929560

BEARING WASHER

WASHER - 19/32" I.D.

8шт.

4

K626376

SHEET

RETAINER - main bearing cap bolts

4шт.

K907322

RING

- dowel, main bearing caps

8шт.

5

K962319

BEARING

RETAINER - oil, Includes: Ref. 6

1шт.

6

K921611

OIL SEAL

PACKING - oil retainer

2шт.

7

K914404

GASKET,0.18mm Thk

- oil retainer

2шт.

K606558

SCREW

HHCS - 5/16" - 18 NC x 1-1/2"

2шт.

8

13-514

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5

4шт.

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

6шт.

9

K622060

PLUG, DRAIN

DRAINCOCK

1шт.

K922093

ADAPTER

- draincock

1шт.

K30421

SEALING WASHER

- sealing, draincock (7/8")

1шт.

10

K609440

PLUG

- 5/8" - 11 NC, oil gallery

1шт.

K15512

WASHER

- copper, 5/8"

1шт.

K623811

PLUG

- Welsh, 2-1/16", camshaft bore

1шт.

11

K623797

PLUG

- core, 1-3/4"

4шт.

12

K907332

TAPPET

COVER - tappet

2шт.

13

K907333

GASKET

- tappet cover

2шт.

14

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

8шт.

K19471

WASHER

- 5/16"

8шт.

K14988

WASHER

- copper - asbestos, 5/16"

8шт.

15

K906538

STUD

- 1/2" - NC to NF x 4-7/8", cylinder head retaining

4шт.

15

K608505

STUD,1/2" x 7/16"

STUD - 1/2" - NC to NF x 5-5/16", cylinder head retaining

2шт.

16

K907297

CARRIER

PLATE - carrier

1шт.

17

K907326

GASKET

- carrier plate

1шт.

18

K907225

COVER

- timing gear

1шт.

19

K907327

GASKET

- timing gear cover

1шт.

20

13-514

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5

6шт.

21

13-46

BOLT,Hex, 1/4" - 20 x 3/8", Gr 5, Full Thd

HHCS - 1/4" - 20 NC x 3/8"

1шт.

22

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

4шт.

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

12шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

23

K623448

SEAL

- oil, 2-1/8" LD. x 2-7/8" I.D. x 3/8" thick (Timing gear cover)

1шт.

K914428

FENDER

GUARD - crankshaft pulley

1шт.

K910610

BUSHING

SPACER

2шт.

13-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

2шт.

24

K907583

GASKET

- left hand, Serial Range: frame-block

1шт.

K907582

GASKET

- right hand, Serial Range: frame-block

1шт.

25

K907584

SEAL

- bearing caps

2шт.

26

13-618

BOLT,Hex, 3/8" - 16 x 1-1/8", Gr 5

9шт.

27

13-6132

BOLT,Hex, 3/8" - 16 x 8-1/4", Gr 5

- special, 3/8" - 16 NC x 8-1/4"

3шт.

28

13-648

BOLT,Hex, 3/8" - 16 x 3", Gr 5

- 3/8" - 16 NC x 3"

1шт.

K914504

BOLT,Spcl, 3/8" - 16 - 7/16" x 8 1/8"

- special, 3/8" - 16 NC

1шт.

K621834

PIN

DOWEL - 7/16" x 1-1/8", Serial Range: frame-block

2шт.

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

14шт.

K961962

SPARE PART

ENGINE complete

1шт.
