Артикул
Название
Примечание
Количество
G1077
SUPPORT - friction plate and hand throttle
1шт.
G1078
PLATE
- friction, hand lever
1шт.
G1079
LEVER
- lower, hand throttle shaft
1шт.
NSS
NOT SOLD SEPARAT
3/32" x 3/4" cotter pin
1шт.
G1081
LEVER - cross shaft
1шт.
G1082
LEVER
- governor control rod
1шт.
G1085
LEVER
HANDLE - throttle
1шт.
G1226
GUIDE - governor control rod
1шт.
NSS
NOT SOLD SEPARAT
5/16" x 1" hex. head bolt UNC w/lockwasher
2шт.
G10743
SHAFT - hand throttle
1шт.
NSS
NOT SOLD SEPARAT
7/16" plain washer, SAE, std.
1шт.
G10745
SHAFT - cross, governor control
1шт.
NSS
NOT SOLD SEPARAT
1/8" x 1" cotter pin
1шт.
G10746
LINK - connecting, throttle
1шт.
NSS
NOT SOLD SEPARAT
3/32" x 3/4" cotter pin
2шт.
G10876
GASKET
FRICTION DISK - throttle, cork
1шт.
G11152
X
BALL AND SOCKET ASSEMBLY
1шт.
NSS
NOT SOLD SEPARAT
1/4" hex. nut UNF and lockwasher
1шт.
G11203
ROD - governor control
1шт.
G45128
LINK
BALL AND SOCKET (double) G1079 lever to G1080 lever
1шт.
O2060FH
X
ROLLPIN - (1/8" x 3/4") use with VTA850
1шт.
O2104FH
X
ROLLPIN - (5/32" x 7/8")
5шт.
O2110FH
X
ROLLPIN - (3/16" x 3/4") pivot, for G1080 and G1081 levers
1шт.
O2717FH
X
ROLLPIN - (5/32" x 1-5/8") for G1085 handle
1шт.
O2742FH
X
ROLLPIN - (1/4" x 3/4"), Serial Range: G1077-G1075
2шт.
V20301
LOCK WASHER
NUT - governor rod adjusting
2шт.
VT540
GEAR (Use VTA857)
1шт.
VT2123
X
SPRING - hand throttle shaft tension
1шт.
VT2434
X
SPRING - control rod lever
1шт.
NSS
NOT SOLD SEPARAT
3/32" x 3/4" cotter pin
1шт.
VT3259
X
SEAL - dust, felt governor shaft
1шт.
VT3288
X
SPACER - thrust, governor shaft
1шт.
VT3351
X
BEARING - governor shaft (Torrington #B610)
1шт.
VT3353
X
BALL - governor arm thrust (3/16" dia.)
1шт.
VT4588
X
SPRING - governor speed control
1шт.
VT4589
ROD - carburetor throttle
1шт.
NSS
NOT SOLD SEPARAT
1/4" hex. nut UNF and Shakeproof washer I.T.
4шт.
VT5113
X
SPRING - hand throttle shaft lever
1шт.
VTA725
BALL JOINT
BALL AND SOCKET ASSEMBLY
1шт.
NSS
NOT SOLD SEPARAT
1/4" hex. nut UNF with lockwasher
1шт.
VTA850
X
LEVER AND ARM ASSEMBLY - governor
1шт.
VTA855
X
GOVERNOR SHAFT ASSEMBLY
1шт.
VTA856
GOVERNOR WEIGHT ASSEMBLY
1шт.
NSS
NOT SOLD SEPARAT
3/16" x 1/2" round head rivet
4шт.
VTA857
X
GOVERNOR WEIGHT AND TIMING GEAR ASSEMBLY
1шт.
36478
ROD - actuating, foot, Serial Range: throttle-bellcrank
1шт.
NSS
NOT SOLD SEPARAT
1/16" x 1/2" cotter pin, foot throttle
1шт.
NSS
NOT SOLD SEPARAT
1/4" hex. jam nut, foot throttle
1шт.
G10762
BRACKET - pivot, foot throttle pedal
2шт.
NSS
NOT SOLD SEPARAT
1/4" x 3/4" NC rd. hd. mach. screw w/hex. nut and lockwasher, foot throttle
4шт.
G13469
BELLCRANK - foot throttle rod to governor control rod lever
1шт.
NSS
NOT SOLD SEPARAT
1/8" x 1" cotter pin, foot throttle
1шт.
NSS
NOT SOLD SEPARAT
7/16" plain washer, foot throttle
2шт.
G13475
PEDAL - foot throttle
1шт.
G16660
TURNBUCKLE - actuating rod to bellcrank, foot throttle
1шт.
G46175
SPACER - bellcrank to cross shaft (3/8" O.D. x 3/8"), foot throttle
1шт.
G47035
SPACER - foot throttle pedal to pivot bracket
1шт.
Выбрано товаров: 58
