Запчасти Case 320 (68) - HYDRAULIC BACKHOE SWING CYLINDERS, *WHEEL TRACTOR (00) - COMPLETE MACHINE

1

38374

WASHER

CYLINDER - swing, hydraulic, (L.H.) original equipment only - use D23252

1шт.

38375

CYLINDER - swing, hydraulic, (R.H.) original equipment only - use D23253

1шт.

D23252

CYLINDER - swing, hydraulic, (L.H.) replacement only

1шт.

D23253

CYLINDER - swing, hydraulic, (R.H.) replacement only

1шт.

1

38871

CYLINDER - swing, hydraulic (Original equipment only - use D23257) , CRAWLER TRACTOR

2шт.

D23257

CYLINDER - swing, hydraulic (Replacement only) , CRAWLER TRACTOR

2шт.

2

D20027

ROD - piston , CRAWLER TRACTOR

1шт.

3

30634

BUSHING,32.05mm ID x 38.18mm OD x 17.6mm L

- piston rod yoke , CRAWLER TRACTOR

2шт.

4

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - straight grease (1/8" NPT) (Lincoln #5000) , CRAWLER TRACTOR

1шт.

5

49482

SNAP RING,2.125", Int, #212

Ring, Snap, , seal, piston rod, crawler tractor 2.125", Int, #212

1шт.

6

36259

WASHER

- packing, piston rod (Use D23962 and D23933) , CRAWLER TRACTOR

1шт.

7

17603

WIPER SEAL

- wiper, piston rod (Use D23962 and D23933) , CRAWLER TRACTOR

1шт.

8

D23962

SEAL

- wiper, piston rod (Also order 1 - D23933 gland when replacing 17603 seal) , CRAWLER TRACTOR

1шт.

9

D23933

GLAND

- seal, wiper (Also order 1 - D23962 seal when replacing 36259 washer ) , CRAWLER TRACTOR

1шт.

10

17597

PACKING

- piston rod , CRAWLER TRACTOR

1шт.

11

30628

CAP - end, cylinder , CRAWLER TRACTOR

1шт.

When replacing cylinder end or cap that has .185" wide "O" ring groove, also order D24985 backup ring, as replacement end or cap has .210" wide "O" ring groove.

1шт.

12

D24985

RING

- leather backup (Used only with cylinder end or cap that has .210" wide "o" ring groove) , CRAWLER TRACTOR

2шт.

D25493

BACK-UP RING

RING - plastic backup (Used only with cylinder end or cap that has .185" wide "o" ring groove) , CRAWLER TRACTOR

2шт.

13

38372

TUBE - cylinder (3" O.D. - 38374, 38375, and 38871 cylinders only) , CRAWLER TRACTOR

1шт.

D23250

TUBE - cylinder (2-7/8" O.D. - D23252, D23253, and D23257 cylinders only) , CRAWLER TRACTOR

1шт.

14

30630

CARTRIDGE

WASHER - packing, piston , CRAWLER TRACTOR

1шт.

15

17598

PACKING

- piston , CRAWLER TRACTOR

1шт.

16

03522CK

SEAL - "o" ring, piston rod (Used with D23738 piston only) , CRAWLER TRACTOR

1шт.

17

30631

X

PISTON - cylinder (No "o" ring) (Use D23738, D23739, and 03522CK) , CRAWLER TRACTOR

1шт.

D23738

BLOCK

PISTON - cylinder (With "o" ring) (When replacing 30631 piston without "o" ring, also order 1 - 03522CK "o" ring and 1 - D23739 locknut) , CRAWLER TRACTOR

1шт.

18

86982912

O-RING

SEAL - "o" ring, cylinder ends to tube , CRAWLER TRACTOR

2шт.

19

131-152

HARDWARE

NUT - lock, hex. (30631 piston only) (3/4" - 16 NF) , CRAWLER TRACTOR

1шт.

D23739

LOCK NUT

NUT - lock, hex. (D23738 piston only) (3/4" - 16 NF) , CRAWLER TRACTOR

1шт.

20

34888

END

- cylinder , CRAWLER TRACTOR

1шт.

When replacing cylinder end or cap that has .185" wide "O" ring groove, also order D24985 backup ring, as replacement end or cap has .210" wide "O" ring groove.

1шт.

21

38369

ROD - tie, short , CRAWLER TRACTOR

4шт.

22

38370

ROD - tie, long , CRAWLER TRACTOR

4шт.

23

230-4616

LOCK NUT,3/8"-24, GA

NUT - lock, hex. (3/8" - 24 NF) , CRAWLER TRACTOR

8шт.

24

D20528

TRUNNION - hydraulic cylinder (For 3" O.D. cylinder tube only) , CRAWLER TRACTOR

1шт.

D21905

TRUNNION - hydraulic cylinder (For 2-7/8" O.D. cylinder tube only) , CRAWLER TRACTOR

1шт.

25

30634

BUSHING,32.05mm ID x 38.18mm OD x 17.6mm L

- cylinder trunnion , CRAWLER TRACTOR

2шт.
