Артикул
Название
Примечание
Количество
1
275820A3
CRANK LEVER
LEVER auxiliary control, detent lever, backhoe, uni-directional flow, activates flow to the attachment through the use of the foot switch, see Figure 4-50 for foot switch
1шт.
2
D59912
KNOB
lever
1шт.
3
275677A1
PIVOT ASSY.
SHAFT pivot, 7 or 8 spool
1шт.
4
614-6025
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd
- hex, full threads, 6 - 1.0 x 25 mm
2шт.
5
829-1406
NUT,Hex, M6 x 1, Cl 10.9
2шт.
6
195-81013
WASHER,33/64" x 7/8" x .033"
flat, 33/64 x 7/8 1/32 inch, used as a shim
3шт.
7
D136635
BLOCK
shifter pivot
1шт.
8
103-3350
SNAP RING,#50, .392" Dia, E-Type
Ring, Retaining, #50, .392" Dia, E-Type
2шт.
9
495-11053
WASHER,1/2", SAE
(17/32" x 1-1/16" x 3/32") 1/2", SAE
1шт.
10
283226A1
SPRING
return
1шт.
12
276070A1
SHAFT
spring pivot
1шт.
13
495-81002
WASHER,3/8"
flat, 7/16 x 1-3/8 x 5/64 inch
1шт.
14
R47941
JOINT TURNING
JOINT ball, male, 3/8 inch NF
1шт.
15
425-156
JAM NUT,Jam, 3/8"-24, G5
hex, jam, 3/8 inch NF
1шт.
16
259410A1
TURNBUCKLE
hex
1шт.
17
129-289
JAM NUT,Jam, 3/8"-24, G5, LH
1шт.
18
257810A1
ROD
control, 7 spool valve, if used
1шт.
18a
283332A1
ROD
control, 8 spool valve, if used
1шт.
19
895-18010
WASHER,10.5mm ID x 18mm OD x 1.6mm Thk
If used M10 x 18 x 1.6
1шт.
20
432-612
COTTER PIN,3/32" x 3/4"
PIN , SPLIT (COTTER), 3/32" x 3/4"
1-2шт.
21
333737A1
ROD
control, 7 spool valve, if used
1шт.
21a
333739A1
ROD
control, 8 spool valve, if used
1шт.
22
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
flat, 9 x 17 x 1.6 mm, If used
2шт.
Выбрано товаров: 24
