Артикул
Название
Примечание
Количество
224453A1
ELEMENT
SECTION ASSEMBLY, hitch auxiliary
1шт.
1
NSS
NOT SOLD SEPARAT
HOUSING valve section
1шт.
2
NSS
NOT SOLD SEPARAT
SPOOL valve section
1шт.
3
N8194
LARGE PLATE
PLATE retainer, seal, outer
1шт.
3a
N7030
LARGE PLATE
PLATE retainer, seal, inner
1шт.
4
193-558
SCREW,SEMS, Slot Fil Hd, 1/4"-20 x 7/8"
slotted, with split lockwasher, 1/4 NC x 7/8 inch
2шт.
5
N7029
SCRAPER
WIPER spool
1шт.
6
D88730
WASHER,0.77" ID x 1.43" OD
RETAINER seal
2шт.
N8880
SEAL
KIT seal, spool
1шт.
7
D88729
WASHER,0.76" ID x 1" OD x 0.05" Thk
RING backup
2шт.
8
N13962
O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro
SEAL lip
2шт.
9
224975A1
PLUNGER
RACE ball
1шт.
10
224976A1
WASHER
PLATE thrust
1шт.
13
224977A1
SPRING
centering, detent
1шт.
14
224979A1
VALVE POPPET
SCREW detent
1шт.
15
211-1007
BALL,7/32" Dia
Gr 24, Chrome alloy steel 7/32" Dia
12шт.
16
224978A1
SPRING
detent
1шт.
17
H267591
SPRING SEAT
SEAT spring
2шт.
18
224980A1
PLUG
CAP adjusting
1шт.
19
224974A1
COVER
CAP valve spool
1шт.
20
193-557
SCREW,SEMS, Sltd Fil Hd, 1/4"-20 x 5/8", G5
slotted, with split lockwasher, 1/4 NCx 5/8 inch
2шт.
21
224794A1
VALVE
ASSEMBLY, circuit relief, upper port, 1000 psi, 6895 kPA, parts list Figure 9-7
1шт.
H593616
VALVE
ASSEMBLY, anti-cavitation
1шт.
22
NSS
NOT SOLD SEPARAT
HOUSING valve
1шт.
23
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
10-1, 90 Duro, .755" ID x .097" Thk
1шт.
Part of Seal Kit, P/N N8883
1шт.
24
L35297
RING,16.18mm ID x 19.07mm OD x 1.42mm Thk
backup
1шт.
Part of Seal Kit, P/N N8883
1шт.
25
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
Part of Seal Kit, P/N N8883
1шт.
26
211-1014
BALL,7/16" Dia
chrome alloy steel, 7/16 inch, grade 24
1шт.
27
NSS
NOT SOLD SEPARAT
SHUTTLE sleeve, anticavitation
1шт.
28
D88725
BACK-UP RING
RING backup
2шт.
Part of Seal Kit, P/N N8883
1шт.
29
238-5015
O-RING,0.07" Thk x 0.551" ID, -15, Cl 5, 75 Duro
-015, 70 Duro, .551" ID x .070" Thk
1шт.
Part of Seal Kit, P/N N8883
1шт.
30
H268730
SPRING
poppet
1шт.
31
D28576
VALVE POPPET
POPPET load check
1шт.
N8883
SEAL KIT
KIT seal, Includes: Ref. 23, 24, 25, 28, and 29
1шт.
Выбрано товаров: 39
