Запчасти Case 680K (5-146) - STEERING WHEEL AND COLUMN (05) - STEERING

1

L102601

LOCK VALVE

VALVE ASSEMBLY - steering control, parts list Figure 5-154

1шт.

2

A65544

STEERING WHEEL

1шт.

3

F19646

LOCK NUT,13/16"-20, Thin

NUT - special, steering wheel mounting

1шт.

4

238-5229

O-RING,0.139" Thk x 2.359" ID, -229, Cl 5, 75 Duro

- cap

1шт.

5

A62210

PLUG

CAP - steering wheel

1шт.

6

D66049

CLAMP

- steering column

1шт.

7

L102644

COLLAR CLAMP

COLLAR - steering column

1шт.

8

413-520

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

- hex head, 5/16" - 18 NC x 1-1/4", plated

2шт.

9

495-21038

WASHER,5/16"

2шт.

10

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

11

425-105

NUT,5/16"-18, G5

- hex, 5/16" - 18 NC, plated

2шт.

12

D95745

BUSHING

SPACER - plate mounting

2шт.

13

413-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

- hex, 3/8 NC x 1-3/4 inch

2шт.

14

492-11038

LOCK WASHER,3/8"

2шт.

15

495-21044

WASHER,3/8"

2шт.

16

L108626

PLATE ASSY.

PLATE - steering mounting

1шт.

17

D52276

ISOLATOR,10.16mm ID x 28.07mm OD x mm L

MOUNT - steering

2шт.

18

88044

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

- hex head, 3/8" - 16 NC x 1-1/2", plted

2шт.

19

D52275

WASHER,9.92mm ID x 31.75mm OD x 2.78mm Thk

- hardened

2шт.

20

231-1446

NUT,3/8" - 16, Gr 5

NUT - hex, self-locking, 3/8"-16 NC, plated

2шт.
