Запчасти Case 580K (09-482) - BACKHOE MOUNTING FRAME AND STABILIZERS (09) - CHASSIS/ATTACHMENTS

31

D144673

SKID/SHOE

PLATE stabilizer, flip over, Category III, if used

2шт.

32

D142314

SKID/SHOE

PAD rubber, if used

6шт.

33

131-1129

LOCK NUT,7/16"-14, GA

NUT hex, self-locking, 7/16"-14 NC, plated, if used

18шт.

34

D144672

PIN

plate to stabilizer leg, if used

2шт.

35

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

If used Hex, 3/8"-16 x 2", G5

4шт.

36

230-4216

LOCK NUT,3/8"-16, GA

NUT hex, self-locking, 3/8" NC, If used

4шт.

37

D142519

SHOE (ASSY)

PLATE stabilizer, street or cemetery, if used

2шт.

38

D39256

AXLE PIN,38.1mm OD x 238.13mm L

PIN, 9-3/8" (238 mm) long, P/N D142519, Serial Range: plate-leg

2шт.
