Запчасти Case 580G (568) - AXIAL BACKHOE - SAFETY DEVICE (09) - CHASSIS/ATTACHMENTS
№
Артикул
Название
Примечание
Количество
1
7770
NUT,Hex, 1/4 - 20, Cl 5
5L
2шт.
2
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
2шт.
3
195-518
WASHER,1/4", SAE
2шт.
4
193-1003
NUT,Keps, w/LW,#6-32
2шт.
5
D134622
SWITCH
micro
1шт.
6
E44499
BRACKET
SPARE PART 5L
1шт.
7
113-2
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
2шт.
8
195-507
WASHER,#6
flat
2шт.
9
182-530
SCREW,Sl Pan Hd, #6 - 32 x 1 1/4"
2шт.
10
515-2348
CLAMP,4.8mm ID, 10.3mm Bolt Hole, P Type
5L
2шт.
11
113-2
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
5L
2шт.
12
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
2шт.
13
7770
NUT,Hex, 1/4 - 20, Cl 5
5L
2шт.
14
E44555
HARNESS
SPARE PART 5L
1шт.
15
E38355
TERMINAL CONNECTOR
CLIP 5L
2шт.
16
E44427
HARNESS
SPARE PART If used
1шт.
16
E46389
HARNESS
1шт.
17
E44501
LEVER
5L
1шт.
18
218-5239
TEE,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB
5L
1шт.
18
218-5008
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
For 5L
1шт.
19
E44522
ADAPTER
SPARE PART Includes: Ref. 19
1шт.
19
E44824
O-RING
SPARE PART
1шт.
20
E44497
VALVE
SPARE PART check
1шт.
21
E44549
FITTING
SPARE PART elbow 5L, Includes: Ref. 21
1шт.
21
E44824
O-RING
SPARE PART 5L
1шт.
22
D50372
HOSE
1шт.
23
E44560
WASHER
SPARE PART
1шт.
24
221-849
PLUG,Hex Soc, 1/8"-27
1шт.
25
83-54
SET SCREW,Hex Soc, 5/16"-18 x 1/4", Cup Pt
1шт.
26
E44305
PLUG
1шт.
27
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
28
E44304
PLUNGER
1шт.
29
E44610
FITTING
restrictor
1шт.
30
L11541
CABLE TIE,203.2mm L, Nylon
CABLE STRAP tie
3шт.
31
E44473
CONNECTOR, ELEC
CONNECTOR plug
1шт.
32
E44474
COIL
SPARE PART, Serial Range: -3.989.425
1шт.
33
E44479
SOLENOID
SPARE PART, Serial Range: -3.989.425
1шт.
NSS
NOT SOLD SEPARAT
CARTRIDGE, Serial Range: -3.989.425
1шт.
E44914
O-RING
inner "0" 0.644, Serial Range: -3.989.425
1шт.
E44915
O-RING
inner "0" 0.364, Serial Range: -3.989.425
1шт.
E44916
BUSHING
Support, inner "0" 0.364, Serial Range: -3.989.425
1шт.
34
E44434
BLOCK ASSY.
SPARE PART CARTRIDGE, Serial Range: -3.989.425
1шт.
35
218-5216
TEE,37 Degree, 1 1/16"-12x1 1/16"-12, Fem Sw Runx1 1/16"-12
1шт.
36
E44433
ADAPTER
SPARE PART
2шт.
37
E44284
ADAPTER
SPARE PART If used, Includes: Ref. 37
1шт.
37
E44824
O-RING
SPARE PART If used
1шт.
38
E44282
VALVE
SPARE PART check, If used
1шт.
39
E44285
ADAPTER
If used
1шт.
40
D120465
HOSE
1шт.
41
E46023
ROD 2L
1шт.
42
E10160
GROMMET
1шт.
43
E44553
BRACKET
2L
1шт.
44
E44550
BLOCK
SPARE PART 2L
1шт.
45
218-5221
TEE,37 Degree, 1 1/16"-12 x 1 1/16"-12, Fem Sw Run
2L
1шт.
46
E44562
HOSE
SPARE PART 2L, If used
1шт.
47
218-5231
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
2L, 218-5175
1шт.
47
218-5175
ELBOW,45 Degree Elbow, 1-1/16" - 12 Male JIC x 1-1/16" - 12 Female JIC
elbow - 45 Degrees 2L
1шт.
48
E42488
COUPLING, BREAK AWAY
SPARE PART elbow 2L, Includes: Ref. 48
1шт.
48
E44824
O-RING
SPARE PART 2L
1шт.
E49192
DECAL
(on LH fender) (Not illustrated), E49267
1шт.
E49267
DECAL
(on LH fender) (Not illustrated)
1шт.
49
E46390
HARNESS
1шт.
50
E45806
BRACKET
2L, For Sweden
1шт.
51
E45804
ROD
2L, For Sweden
1шт.
52
195-522
WASHER,5/16"
flat 2L, For Sweden
1шт.
E45966
BLOCK
SPARE PART SOLENOID VALVE ASSY, Includes: Ref. 53 - 63
1шт.
53
NSS
NOT SOLD SEPARAT
BLOCK, Start Serial: 3.989.426
1шт.
54
NSS
NOT SOLD SEPARAT
PLATE name, Start Serial: 3.989.426
1шт.
55
E46556
LOCK VALVE
SOLENOID, Includes: Ref. 56 - 63, Start Serial: 3.989.426
1шт.
56
NSS
NOT SOLD SEPARAT
COIL, Start Serial: 3.989.426
1шт.
57
NSS
NOT SOLD SEPARAT
SEAT, Start Serial: 3.989.426
1шт.
58
NSS
NOT SOLD SEPARAT
POPPET, Start Serial: 3.989.426
1шт.
59
NSS
NOT SOLD SEPARAT
SEAL, Start Serial: 3.989.426
1шт.
60
NSS
NOT SOLD SEPARAT
SEAL, Start Serial: 3.989.426
1шт.
62
E46558
O-RING
, Start Serial: 3.989.426
1шт.
63
E46559
O-RING
backup, Start Serial: 3.989.426
1шт.
61
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
, Start Serial: 3.989.426
1шт.
Выбрано товаров: 77
