Запчасти Case 580G (492) - AIR CONDITIONER (09) - CHASSIS/ATTACHMENTS

1

D84781

CONDENSER

1шт.

2

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

4шт.

3

195-525

WASHER,3/8", SAE

4шт.

4

222-993

GASKET,3/8 Tube, Fl, Copper

2шт.

5

92-6

LOCK WASHER,3/8"

4шт.

6

25-106

NUT,3/8"-16, G5

4шт.

7

13-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

6шт.

8

92-4

LOCK WASHER,1/4"

6шт.

9

95-4

WASHER,1/4"

flat

6шт.

10

D121386

GUARD

SPARE PART

1шт.

11

214-258

HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm

2шт.

12

D88358

HOSE

1шт.

13

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

4шт.

14

195-525

WASHER,3/8", SAE

4шт.

15

D121536

CLUTCH

SPARE PART

1шт.

16

D121129

FAN

1шт.

17

13-514

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5

4шт.

18

REF

INSTRUCTION

HOSE (See Figure 493A)

1шт.

19

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

2шт.

20

D84791

HOSE

1шт.

21

195-525

WASHER,3/8", SAE

2шт.

22

92-6

LOCK WASHER,3/8"

2шт.

23

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

2шт.

24

92-6

LOCK WASHER,3/8"

2шт.

25

13-624

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

2шт.

26

L18331

CABLE TIE,375.9mm L, Nylon, Black

CABLE STRAP

7шт.

27

129-103

NUT,Hex, 3/8" - 16, Gr 5

1шт.

28

D93744

BRACE

SPARE PART

1шт.

29

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

1шт.

30

92-6

LOCK WASHER,3/8"

1шт.

31

D90310

HOSE

1шт.

32

D120189

HOSE

1шт.

33

D87966

FILTER SCREEN

1шт.

34

222-994

GASKET,1/2 Tube, Fl, Copper

1шт.

35

REF

INSTRUCTION

VALVE (See Figure 64)

1шт.

36

222-995

SEALING WASHER,15.88mm ID

1шт.

37

REF

INSTRUCTION

VALVE (See Figure 64)

1шт.

38

REF

INSTRUCTION

COMPRESSOR (See Figure 64)

1шт.

39

A162008

CLUTCH

1шт.

40

REF

INSTRUCTION

BOLT (See Figure 26)

4шт.

41

REF

INSTRUCTION

COUPLING (See Figure 26)

1шт.

42

K944348

PULLEY

1шт.

43

REF

INSTRUCTION

HARNESS (See Figure 493A)

1шт.
