Запчасти Case 580G (488) - CAB - HEATER SEE FIGURE 486 UP TO NO. 3.808.596 (09) - CHASSIS/ATTACHMENTS

1

K19500

GASKET

2шт.

2

D76514

FITTING

2шт.

3

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

8шт.

4

D121517

LARGE HOSE

HOSE,LARGE

2шт.

5

D39696

CLAMP,25.40mm - 13.49mm Bolt, CTD

1шт.

6

E44958

LOOM

SHEATH

2шт.

7

D120093

LOOM

SHEATH

2шт.

8

L18331

CABLE TIE,375.9mm L, Nylon, Black

CABLE STRAP

2шт.

9

195-521

WASHER,5/16", SAE

3шт.

10

D121498

TUBE

("0" inter : . 49")

1шт.

D123482 + D123483 + D123484 + 113-110

1шт.

10

D123483

TUBE

("0" inter : . 53")

1шт.

11

D121496

TUBE

("0" inter : . 49")

1шт.

D123482 + D123483 + D123484 + 113-110

1шт.

11

D123482

TUBE

("0" inter : . 53")

1шт.

12

113-122

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

3шт.

12

113-110

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

3шт.

13

L100813

LARGE HOSE,0.63" ID x 4.00", SAE 20R3

HOSE,LARGE

2шт.

14

9635082

NUT,5/16" - 18, Gr 5

3шт.

15

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

3шт.

16

R46103

SPACER

3шт.

17

D121500

CLAMP

SPARE PART

3шт.

18

D123539

BUSHING

3шт.

19

D123484

BUSHING

(If used)

1шт.
