Запчасти Case 580G (480) - CAB - HEADLINER AND WINDSHIELD WIPER COVERS (09) - CHASSIS/ATTACHMENTS

1

F44768

LINING

head, Serial Range: -3.804.046

1шт.

1

F45200

COVER ASSY

head, Serial Range: 3.804.047-3.804.820

1шт.

1

F45265

head, Serial Range: 3.804.821-3.808.596

1шт.

1

E45773

LINING

head, Start Serial: 3.808.597

1шт.

2

F41978

JOURNAL

head front, Serial Range: -3.804.046

1шт.

2

F45202

PLATE

head front, Serial Range: 3.804.047-3.804.820

1шт.

2

F45266

MOLDING

head front, Serial Range: 3.804.821-3.808.596

1шт.

3

F64132

GUARD

ball type, Serial Range: -3.804.046

6шт.

4

F64131

RING

retainer, Serial Range: -3.804.046

6шт.

5

F45103

LINING

SPARE PART head rear, Serial Range: -3.804.046

1шт.

5

F45201

LINING

head rear, Serial Range: 3.804.047-3.804.820

1шт.

5

F45267

LINING

head rear, Serial Range: 3.804.821-3.808.596

1шт.

6

L109555

GUARD

slat type

5-3шт.

7

187-1084

SELF-TAP SCREW,Cross Oval Hd, #10 x 3/4"

, Serial Range: -3.804.046

18-34шт.

7a

F63765

WASHER

, Serial Range: -3.804.046

18-34шт.

8

F42918

COVER

, Serial Range: -3.804.820

1шт.

8

F45222

COVER

, Serial Range: 3.804.821-3.808.596

1шт.

9

187-1098

SELF-TAP SCREW,Cross Oval Hd, #10 x 3/4"

F64519

8шт.

9

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

special

8шт.

Used in place of 187-1098 + F64315 (if used)

1шт.

10

F64315

WASHER

F64519

8шт.

11

F42781

COVER

, Serial Range: -3.804.820

1шт.

11

F45221

MOLDING

cover, Serial Range: 3.804.821-3.808.596

1шт.

12

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

3шт.

13

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

3шт.

14

7770

NUT,Hex, 1/4 - 20, Cl 5

3шт.

15

F42837

BRACKET

, Serial Range: -3.808.596

2шт.

16

F41977

BRACKET

, Serial Range: -3.808.596

1шт.

17

F42836

BRACKET

, Serial Range: -3.808.596

1шт.

18

182-540

SCREW,Sl Pan Hd, 1/4" - 20 x 3/8"

without rear windshield wiper

3шт.

19

129-723

RETAINER

without rear windshield wiper

3шт.

20

131-1280

JAM NUT,Jam, 1/4"-20

Without rear windshield wiper

3шт.

21

131-861

SPRING NUT,Tinn, U, #10-24

1шт.

22

F64519

SELF-TAP SCREW,Cross Wash Hd, #10-16 x 3/4"

special, Serial Range: -3.808.596

18-22шт.

23

E45441

CLIP

STUD, Trimount, Start Serial: 3.808.597

20шт.

24

353-403

PLUG,Dome, .437" hole, Nylon

If used

4шт.

25

353-406

PLUG,Dome, .625" hole, Nylon

If used

1шт.
