Запчасти Case 580G (398) - BACKHOE - DIPPER AND BUCKET (09) - CHASSIS/ATTACHMENTS

D128946

ARM

DIPPER ASSY, Includes: Ref. 1 - 6

1шт.

D77895

BOOM

DIPPER ASSY, D128946, Includes: Ref. 1 - 6

1шт.

1

NSS

NOT SOLD SEPARAT

DIPPER

1шт.

2

D43940

BUSHING,44.68mm ID x 57.15mm OD x 25.4mm L

2шт.

3

D31142

BUSHING,51.02mm ID x 63.5mm OD x 38.1mm L

2шт.

4

D34340

BUSHING,44.68mm ID x 53.98mm OD x 25.4mm L

If used

2шт.

5

D50146

BUSHING,44.68mm ID x 57.15mm OD x 38.1mm L

2шт.

6

D55626

BUSHING,44.68mm ID x 57.15mm OD x 41.91mm L

2шт.

7

D52522

PIN,44.45mm OD x 211.84mm L

1шт.

8

51200255

SEALING WASHER,45.77mm ID x 62.18mm OD x 1.59mm Thk

1шт.

9

D25280

SNAP RING,#175, Ext

2шт.

10

195-2152

WASHER,1 13/16" x 2 1/2" x .109"

flat

2шт.

11

REF

INSTRUCTION

CYLINDER, See Figure 332

1шт.

12

D61244

LINK

ASSY, Includes: Ref. 13 and 14, Serial Range: -3.918.631

2шт.

13

D37495

BUSHING,44.76mm ID x 57.15mm OD x 31.75mm L

, Serial Range: -3.918.631

1шт.

14

D30933

BUSHING,38.41mm ID x 47.63mm OD x 31.75mm L

, Serial Range: -3.918.631

1шт.

15

195-2152

WASHER,1 13/16" x 2 1/2" x .109"

flat

2шт.

16

D93227

BUSHING

1шт.

17

D37614

PIN,38mm Od x 246mm L

1шт.

18

D28610

WASHER,38.5mm ID x 63.5mm OD x 2.66mm Thk

2шт.

19

D25279

SNAP RING,M35, Int

2шт.

21

E35389

LINK

ASSY, Includes: Ref. 22 and 23, Serial Range: -3.918.631

2шт.

22

D46405

BUSHING,44.68mm ID x 53.98mm OD x 19.05mm L

, Serial Range: -3.918.631

1шт.

23

D42788

BUSHING,44.68mm ID x 53.98mm OD x 28.57mm L

, Serial Range: -3.918.631

1шт.

24

D77725

WASHER

2шт.

25

D53818

PIN,44.45mm OD x 278.89mm L

2шт.

26

195-2152

WASHER,1 13/16" x 2 1/2" x .109"

flat

1шт.

27

51200255

SEALING WASHER,45.77mm ID x 62.18mm OD x 1.59mm Thk

1шт.

28

D25280

SNAP RING,#175, Ext

4шт.

29

D64799

PIN,44.45mm OD x 370.84mm L

(Long : 14.57")

1шт.

30

D55584

PIN,44.45mm OD x 327.15mm L

(Long : 12.88")

1шт.

31

195-2152

WASHER,1 13/16" x 2 1/2" x .109"

flat

1шт.

32

D25280

SNAP RING,#175, Ext

2шт.

33

219-1

LUBE NIPPLE,1/8" - 27 NPTF

2шт.

34

REF

INSTRUCTION

BUCKET, See Figure 404 - 412

1шт.

35

D89620

LINK

ASSY, Includes: Ref. 36, Start Serial: 3.918.632

2шт.

36

D46405

BUSHING,44.68mm ID x 53.98mm OD x 19.05mm L

, Start Serial: 3.918.632

2шт.

37

D126492

LINK

ASSY, Includes: Ref. 38 and 39, Start Serial: 3.918.632

2шт.

37

E45145

BUCKET

LINK ASSY (with safety hook), For lifting application, Includes: Ref. 38 and 39

1шт.

38

D121845

BUSHING,44.68mm ID x 57.15mm OD x 70mm L

, Start Serial: 3.918.632

1шт.

39

D30933

BUSHING,38.41mm ID x 47.63mm OD x 31.75mm L

, Start Serial: 3.918.632

1шт.

40

E46312

DRAG LINK

SPARE PART ASSY, Includes: Ref. 41, For 185 degrees roll-out

2шт.

41

D46405

BUSHING,44.68mm ID x 53.98mm OD x 19.05mm L

For 185 degrees roll-out

3шт.

42

E46314

DRAG LINK

ASSY, Includes: Ref. 42 and 43, For 185 degrees roll-out

2шт.

43

D121845

BUSHING,44.68mm ID x 57.15mm OD x 70mm L

For 185 degrees roll-out

1шт.

44

D39133

BUSHING, For 185 degrees roll-out

1шт.

45

E46318

SPACER

For 185 degrees roll-out

2шт.

46

E46319

SPACER

SPARE PART For 185 degrees roll-out

1шт.

47

D53818

PIN,44.45mm OD x 278.89mm L

For 185 degrees roll-out

1шт.

48

195-2152

WASHER,1 13/16" x 2 1/2" x .109"

flat, For 185 degrees roll-out

2шт.

49

51200255

SEALING WASHER,45.77mm ID x 62.18mm OD x 1.59mm Thk

flat, For 185 degrees roll-out

2шт.

50

D25280

SNAP RING,#175, Ext

For 185 degrees roll-out

2шт.
