Запчасти Case 580G (374) - SIDESHIFT BACKHOE - EXTENDABLE DIPPER CONTROL - UP TO NO. 3.948.949 (09) - CHASSIS/ATTACHMENTS

1

D87866

PEDAL

1шт.

2

D87854

BRACKET

1шт.

3

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

4шт.

4

92-6

LOCK WASHER,3/8"

4шт.

5

25-106

NUT,3/8"-16, G5

4шт.

6

D87860

LEVER

D126938 + D126940

1шт.

6

D126938

LEVER

1шт.

7

138-136

LOCK PIN,1/4" x 1 1/4", Slotted

1шт.

8

D92177

ROD

D126938 + D126940

1шт.

8

D126940

ROD

1шт.

9

D85869

BELLOWS

BOOT

1шт.

10

195-25

WASHER,3/8"

1шт.

11

132-26

COTTER PIN

3/32" x 3/4"

1шт.

12

25-116

NUT,Hex, 3/8"-24, G5

1шт.

13

213-4

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

1шт.

14

141-54

CLEVIS PIN,3/8" x 1 1/16"

1шт.

15

132-26

COTTER PIN

3/32" x 3/4"

1шт.

16

D87863

PLATFORM

1шт.

17

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

2шт.

18

92-6

LOCK WASHER,3/8"

2шт.

19

25-106

NUT,3/8"-16, G5

2шт.

20

219-56

LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF

1шт.

21

D88476

LEVER

bellcrank

1шт.

22

86636814

LUBE NIPPLE,1/4"-28 x .52" lg

1шт.

23

D91903

LINK

1шт.

24

141-54

CLEVIS PIN,3/8" x 1 1/16"

1шт.

25

D88430

PIN,7.9mm OD x 26.47mm L

clevis

1шт.

26

132-26

COTTER PIN

3/32" x 3/4"

2шт.

27

REF

INSTRUCTION

VALVE control, See Figure 288

1шт.

28

13-832

BOLT,Hex, 1/2" - 13 x 2", Gr 5

3шт.

29

95-8

WASHER,1/2"

flat

6шт.

30

131-654

LOCK NUT,1/2"-13, GB

3шт.
