Запчасти Case 580F (362) - FLAP SEAT, FOR GERMANY (55) - ELECTRICAL SYSTEMS

1

E30716

CUSHION ASSY.

SPARE PART

1шт.

2

138-54

LOCK PIN,1/8" x 9/16", Slotted

1шт.

3

E30755

SCREW

4шт.

4

E34629

PLATE ASSY.

BRACKET

1шт.

5

E15520

SPARE PART

PIN

2шт.

6

E30745

AXLE PIN

1шт.

7

E30867

SPARE PART

FASTENER

1шт.

8

13-58

BOLT,Hex, 5/16" - 18 x 1/2", Gr 5

2шт.

9

92-5

LOCK WASHER,5/16"

2шт.

10

E30791

LATCH ASSY.

FASTENER

1шт.

11

E30748

BRACKET

1шт.

12

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

Cap

3шт.

13

192-21

LOCK WASHER,3/8"

3шт.

14

195-522

WASHER,5/16"

3шт.

15

E34624

BRACKET

1шт.
