Запчасти Case 580F (041A) - ELECTRICAL INSTRUMENT PANEL, STARTING WITH NO 3.736.448 (55) - ELECTRICAL SYSTEMS

1

E40278

HARNESS

main

1шт.

UP TO NO. 3.737.722

1шт.

1

E40864

HARNESS

main

1шт.

STARTING WITH NO. 3.737.723

1шт.

2

E40263

ELECTRICAL WIRE

WIRE

1шт.

3

182-143

SCREW,Cross Pan Hd, #10 - 32 x 3/8"

1шт.

4

92-3

LOCK WASHER,#10

1шт.

5

129-37

NUT,#10-32

1шт.

6

193-6

LOCK WASHER,Ext Tooth, #10

1шт.

7

D63293

SENDER UNIT

SENDER SENSOR

1шт.

8

D75465

SCREW,#10 - 32 x 5/8"

4шт.

9

A11822

GASKET

1шт.

10

E41294

CLAMP

1шт.

11

25-106

NUT,3/8"-16, G5

1шт.

12

A34868

CLAMP

1шт.

13

A65550

FLASHER UNIT

1шт.

14

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

14

92-5

LOCK WASHER,5/16"

1шт.

14

9635082

NUT,5/16" - 18, Gr 5

1шт.

15

D52008

SWITCH

turn signal

1шт.

16

A20468

SCREW,Spcl, #8 - 32 x 5/16"

1шт.

17

A20465

KNOB

1шт.

18

A20467

NUT

1шт.

19

193-35

LOCK WASHER,Int Tooth, 3/4"

1шт.

20

E40271

HARNESS

SPARE PART

1шт.

21

353-406

PLUG,Dome, .625" hole, Nylon

1шт.

22

E40328

PLATE

SPARE PART

1шт.

23

K929365

IGNITION SWITCH

key starting

1шт.

K920929

KEY

2шт.

E40114

KEY

for Germany only

2шт.

24

182-525

SCREW,Sl Pan Hd, #10 - 32 x 3/8"

2шт.

UP TO NO. 3.736.782

1шт.

24

E41293

RIVET

2шт.

STARTING WITH NO. 3.736.783

1шт.

25

193-6

LOCK WASHER,Ext Tooth, #10

2шт.

UP TO NO. 3.736.782

1шт.

26

129-37

NUT,#10-32

2шт.

UP TO NO. 3.736.782

1шт.

27

353-402

PLUG,Dome, .375" hole, Nylon

4-5шт.

28

E40371

LIGHT SWITCH

light

1шт.

29

E40327

BUSHING

SPARE PART SPACER, if used

1шт.

30

E40329

PLATE

SPARE PART

1шт.

31

E40372

KNOB

1шт.

32

182-525

SCREW,Sl Pan Hd, #10 - 32 x 3/8"

2шт.

32

E41293

RIVET

2шт.

STARTING WITH NO. 3.736.783

1шт.

UP TO NO. 3.736.782

1шт.

33

193-6

LOCK WASHER,Ext Tooth, #10

2шт.

UP TO NO. 3.736.782

1шт.

34

129-37

NUT,#10-32

2шт.

UP TO NO. 3.736.782

1шт.

35

E40273

ELECTRICAL WIRE

SPARE PART HARNESS

1шт.

36

E40321

BOX, FUSE

1шт.

37

E40322

FUSE

BOX

1шт.

38

182-528

SCREW,Sl Pan Hd, #10 - 32 x 1/2"

1шт.

38

193-6

LOCK WASHER,Ext Tooth, #10

1шт.

38

129-37

NUT,#10-32

1шт.

39

D74330

SWITCH

2шт.

40

D70447

KNOB

1шт.

41

D70448

KNOB

1шт.

42

813-5030

BOLT,Hex, M5 x 0.8 x 30mm, Cl 8.8

SCREW

4шт.

42

592-3

WASHER

4шт.

42

525-3

NUT

4шт.

43

D67743

SWITCH

tell tale

1шт.

44

353-404

PLUG,Dome, .500" hole, Nylon

Dry clutch

1шт.

45

353-401

PLUG,Dome, .312" hole, Nylon

dry clutch

3шт.

46

D68716

CABLE

1шт.

47

L11760

DIODE

2шт.

48

L18331

CABLE TIE,375.9mm L, Nylon, Black

CABLE STRAP Clamp

1шт.

49

E40272

HARNESS

1шт.

50

E40274

HARNESS

1шт.

51

182-144

SCREW

4шт.

UP TO NO. 3.737.722

1шт.

52

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

4шт.

UP TO NO. 3.737.722

1шт.

53

195-13

WASHER,#10

4шт.

UP TO NO. 3.737.722

1шт.

54

A33976

SWITCH

torque converter

1шт.

UP TO NO. 3.737.722

1шт.

55

A33977

SWITCH

stop, left-hand

1шт.

UP TO NO. 3.737.722

1шт.

56

A33976

SWITCH

stop, right-hand

1шт.

UP TO NO. 3.737.722

1шт.

57

182-528

SCREW,Sl Pan Hd, #10 - 32 x 1/2"

torque converter

2шт.

UP TO NO. 3.737.722

1шт.

58

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

Torque converter

2шт.

UP TO NO. 3.737.722

1шт.

59

195-13

WASHER,#10

torque converter

2шт.

UP TO NO. 3.737.722

1шт.

60

E35791

BRACKET

STRAP, torque converter

1шт.

UP TO NO. 3.737.722

1шт.

61

D67251

SWITCH

torque converter

1шт.

62

E40330

FUSE

30 amp

1шт.

63

E40332

FUSE

8 amp

7-8шт.

64

E40826

BRACKET

SUPPORT right-hand, torque converter

1шт.

STARTING WITH NO. 3.737.723

1шт.

65

E40827

BRACKET

SUPPORT left-hand, torque converter

1шт.

STARTING WITH NO. 3.737.723

1шт.

66

13-416

BOLT,Hex, 1/4" - 20 x 1", Gr 5

Torque converter

2шт.

STARTING WITH NO. 3.737.723

1шт.

195-18

WASHER,1/4"

torque converter

4шт.

STARTING WITH NO. 3.737.723

1шт.

92-4

LOCK WASHER,1/4"

Torque converter

2шт.

STARTING WITH NO. 3.737.723

1шт.

25-104

NUT,1/4"-20, G5

Torque converter

2шт.

STARTING WITH NO. 3.737.723

1шт.

67

D84030

SWITCH

torque converter

3шт.

STARTING WITH NO. 3.737.723

1шт.

68

D84102

BRACKET

SUPPORT, dry clutch

1шт.

STARTING WITH NO. 3.737.723

1шт.

69

D84102

BRACKET

SUPPORT, dry clutch

1шт.

STARTING WITH NO. 3.737.723

1шт.

70

13-416

BOLT,Hex, 1/4" - 20 x 1", Gr 5

Dry clutch

2шт.

STARTING WITH NO. 3.737.723

1шт.

195-18

WASHER,1/4"

dry clutch

4шт.

STARTING WITH NO. 3.737.723

1шт.

92-4

LOCK WASHER,1/4"

Dry clutch

2шт.

STARTING WITH NO. 3.737.723

1шт.

25-104

NUT,1/4"-20, G5

Dry clutch

2шт.

STARTING WITH NO. 3.737.723

1шт.

71

D84030

SWITCH

dry clutch

2шт.

STARTING WITH NO. 3.737.723

1шт.

72

353-401

PLUG,Dome, .312" hole, Nylon

6шт.

STARTING WITH NO. 3.736.593

1шт.
