Запчасти Case 580F (148) - HYDRAULIC, POWER SHUTTLE TRANSMISSION, WITH OIL COOLER PEERLESS (21) - TRANSMISSION

1

D69685

BRACKET

SPARE PART

2шт.

2

92-6

LOCK WASHER,3/8"

4шт.

3

25-106

NUT,3/8"-16, G5

4шт.

4

D71789

BUSHING

4шт.

5

D41160

CLAMP

4шт.

6

92-6

LOCK WASHER,3/8"

4шт.

7

25-106

NUT,3/8"-16, G5

4шт.

8

D69665

COOLER

oil

1шт.

9

D69050

HOSE

1шт.

10

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

2шт.

11

D69676

TUBE

1шт.

12

13-610

BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd

1шт.

13

92-6

LOCK WASHER,3/8"

1шт.

14

D68638

CLAMP

1шт.

15

D67296

GROMMET

rubber

4шт.

16

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

3шт.

17

92-6

LOCK WASHER,3/8"

3шт.

18

D68646

CLAMP

3шт.

19

D71789

BUSHING

3шт.

20

D68686

HOSE,12.7mm ID x 480mm L, SAE 100R3

1шт.

21

D68972

CONNECTOR, ELEC

CONNECTOR

1шт.

22

D55583

HOSE,12.7 mm ID x 101.60 mm, SAE 100R3

1шт.

23

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

2шт.

24

D68914

TUBE,12 mm OD x 111, 75 mm L

1шт.

25

D48540

VALVE POPPET

1шт.

26

221-423

TEE,3/8" NPT

1шт.

27

D48539

FITTING

elbow, 90 deg.

1шт.

28

218-444

HYD CONNECTOR,3/4" - 16 Male JIC x 3/8" - 18 Male NPTF

1шт.

29

D68262

TUBE

1шт.

30

218-484

ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/8" - 18 Male NPTF

elbow

1шт.

quantity is 1 or 2

1шт.

31

D68260

TUBE

1шт.

32

D68687

HOSE

1шт.

33

D76365

TUBE

1шт.

34

D69050

HOSE

1шт.

35

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

2шт.
