Запчасти Case 580F (268) - AXIAL BACKHOE, CONTROL TOWER (84) - BOOMS, DIPPERS & BUCKETS

1

E40821

LINING

FOAM

1шт.

2

E35624

RUBBER

1шт.

3

E40200

PLATE

1шт.

4

E40203

GUARD

2шт.

5

E40204

GUARD

2шт.

6

13-636

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

2шт.

7

92-6

LOCK WASHER,3/8"

2шт.

8

25-106

NUT,3/8"-16, G5

2шт.

9

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

2шт.

10

92-6

LOCK WASHER,3/8"

2шт.

11

195-25

WASHER,3/8"

2шт.

12

E40195

ANGLE, R.H.

1шт.

13

E40197

ANGLE, L.H.

1шт.

14

13-636

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

2шт.

15

92-6

LOCK WASHER,3/8"

2шт.

16

25-106

NUT,3/8"-16, G5

2шт.

17

E40101

PADDING

2шт.

18

E40099

PLATE, rear

2шт.

19

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

2шт.

20

95-6

WASHER,3/8"

2шт.

21

92-6

LOCK WASHER,3/8"

2шт.

22

25-106

NUT,3/8"-16, G5

2шт.

23

13-636

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

2шт.

24

95-6

WASHER,3/8"

2шт.

25

92-6

LOCK WASHER,3/8"

2шт.

26

25-106

NUT,3/8"-16, G5

2шт.

27

E40085

PLATE

1шт.

28

E40819

ENCLOSURE, Includes: Ref. 29

1шт.

29

E40820

FOAM

1шт.

30

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

6шт.

31

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

6шт.

32

195-521

WASHER,5/16", SAE

6шт.

33

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

1шт.

34

195-25

WASHER,3/8"

2шт.

35

92-6

LOCK WASHER,3/8"

1шт.

36

25-106

NUT,3/8"-16, G5

1шт.

37

E40188

PANEL, center, standard

1шт.

38

E40193

PANEL, center, with hydraulic boom lock

1шт.

39

E41163

GUARD

2шт.

40

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

2шт.

41

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

2шт.

42

195-521

WASHER,5/16", SAE

2шт.
