Артикул
Название
Примечание
Количество
1
L54563
KNOB
- control lever
1шт.
2
L103011
LEVER
- control, clam bucket
1шт.
3
L103233
BRACKET
- pivot
1шт.
4
113-208
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
2шт.
5
192-21
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
6
129-103
NUT,Hex, 3/8" - 16, Gr 5
NUT, 3/8"-16, G5
2шт.
7
T25683
SNAP RING,#75, Ext
Ring, Snap, , pivot #75, Ext
1шт.
9
D38296
JOINT
BALL JOINT - 3/8"
1шт.
10
86585245
SPECIAL NUT,JAM, 5/8" - 18
- hex, jam, 3/8" - 16 NC, plated
2шт.
11
L109751
SEAL
SEAL - control rod
1шт.
12
L103020
ROD
- lever, clam bucket
1шт.
13
213-3
ADJUSTABLE CLEVIS,5/16"-24
CLEVIS - 5/16", rod end
1шт.
14
86637933
JAM NUT,5/16" - 24, Gr 5
1шт.
15
141-53
CLEVIS PIN,5/16" x .940"
plated 5/16" x .940"
1шт.
16
132-320
COTTER PIN,3/32" x 3/4"
PIN, SPLIT (COTTER), 3/32" x 3/4"
1шт.
17
D138276
VALVE
ASSEMBLY - loader control, three spool, clam bucket, parts list Figure 8-58
1шт.
Выбрано товаров: 17
