Запчасти Case 780C (9-430) - STANDARD SEAT AND MOUNTING PARTS (09) - CHASSIS/ATTACHMENTS

1

D123196

SEAT ASSY.

standard parts list Figure 9-434

1шт.

2

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

4шт.

3

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

4шт.

4

D124104

SUPPORT ASSY.

standard seat, with tube for seat belt mounting, parts list Figure 9-438

1шт.

5

113-2441

BOLT,Hex, 1/2" - 13 x 2", Gr 8

4шт.

6

192-23

LOCK WASHER,1/2"

4шт.

7

195-106

WASHER,1/2"

flat, plated

4шт.

8

D75428

SAFETY BELT

2" (51 mm) wide, No longer available, Order L117001 seat belt

1шт.

8a

L117001

SAFETY BELT ,1.80" W

If used

1шт.

8a

D83760

SAFETY BELT

3" (76 mm) wide, if used

1шт.

9

F42236

STEP BOLT

special

2шт.

10

196-7

WASHER - flat, 7/16", hardened, plated

2шт.
