Запчасти Case 780C (2-16) - AIR CLEANER AND AIR INTAKE PARTS (02) - ENGINE

1

A173852

FILTER ASSY

air, engine, parts list Figure 2-18

1шт.

2

L10659

CAP

air cleaner, Includes: Ref. 3

1шт.

3

214-269

HOSE CLAMP,#72, 4.06" - 5", Type F Worm

cap

1шт.

4

S112515

ELBOW

90 degree, reducing, at air cleaner

1шт.

5

214-265

HOSE CLAMP,#56, 3.06" - 4", Type F Worm

elbow to air cleaner

2шт.

6

L111570

TUBE

SPARE PART air, Serial Range: cleaner-engine

1шт.

7

L110814

ELBOW

90 degree, reducing, at engine

1шт.

8

214-264

HOSE CLAMP,#52, 2.81" - 3.75", Type F Worm

elbow to engine

2шт.

9

A149780

BAND

air cleaner mounting

2шт.

10

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

4шт.

11

195-521

WASHER,5/16", SAE

4шт.

12

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

4шт.

13

9635082

NUT,5/16" - 18, Gr 5

4шт.

14

221-365

ELBOW,45 Degree, 1/8" NPT

45 degree, air cleaner

1шт.

15

D36264

FITTING

filter, air restriction indicator

1шт.

16

221-1335

COUPLING,Pipe, 1/8" NPT

1шт.

17

L103131

INDICATOR

air filter restriction indicator

1шт.
