Запчасти Case 780B (090) - ELECTRICAL SYSTEM, REAR HARNESS AND CONNECTIONS (04) - ELECTRICAL SYSTEMS

1

L107332

HARNESS

- rear, used before tractor SN 9151365, Includes: Ref. 1B

1шт.

1a

L110150

HARNESS

- rear, used on tractor SN 9151365 and after, Includes: Ref. 1B

1шт.

1b

N7321

ROD, CONNECTING

CONNECTOR - two pin

1шт.

2

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

12шт.

3

L109945

TRANSMITTER

SENDER - air pressure

1шт.

4

L57937

SWITCH

- air parking brake, used before tractor SN 9145071

1шт.

4

D65457

SWITCH

- air parking brake, used on tractor SN 9145071 and after

1шт.

5

L104249

SWITCH

SENDER - converter oil temperature

1шт.

6

L47989

SWITCH

- stop light, Includes: Ref. 7 - 15

1шт.

7

NSS

NOT SOLD SEPARAT

BODY - switch

1шт.

8

L33201

DIAPHRAGM

- piston

1шт.

9

L33202

PISTON

- switch

1шт.

10

L33203

TERMINAL STRIP

STRIP - contact

1шт.

11

L33204

SPRING

- piston return

1шт.

12

L33205

GASKET

- cover

1шт.

13

L33206

COVER

- switch

1шт.

14

193-6

LOCK WASHER,Ext Tooth, #10

WASHER, LOCK, Ext Tooth, #10

2шт.

15

182-127

SCREW,Sl Pan Hd, #10 - 24 x 3/4"

- slotted pan head, No. 10 - 24 NC x 3/4"

2шт.

15a

E114399

SWITCH

- neutral start

1шт.

16

192-6

LOCK WASHER,#8

WASHER, LOCK, #8

3шт.

17

182-82

SCREW,Slotted Pan Hd, #8-32 x 1/4"

3шт.

18

L101635

SWITCH

- clutch pressure, threaded terminals (order D109377 and L36238 for service)

1шт.

The L36238 electrical repair kit, not shown, contains instructions, (4) 223- 59 eyelet, (2) 223-250 splice, (1) 223-61 eyelet and (2) 353-406 5/8" plug.

1шт.

18a

L109377

SWITCH

- clutch pressure, blade type terminals

1шт.

19

221-138

NIPPLE, LUBE,Nipple, 1/4" NPT x 2 1/2"

NIPPLE - 1/4" NPT, clutch pressure switch

1шт.

20

221-1366

ELBOW

- 1/4" NPT, 45 degree

1шт.

21

221-84

REDUCER,Hex, 1/4" x 1/8" NPT

BUSHING - clutch pressure switch, used with Ref. 18

1шт.

22

66297

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

- 5/16", harness

2шт.

23

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

2шт.

24

95-6

WASHER,3/8"

- flat, 3/8"

2шт.

25

92-6

LOCK WASHER,3/8"

2шт.

26

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

2шт.

27

221-1088

REDUCER,Hex, 1/2" x 1/4" NPT

ADAPTER - 1/2" NPT x 1/4" NPT

2шт.

28

L70507

SWITCH

- low air pressure

1шт.

29

92-3

LOCK WASHER,#10

WASHER, LOCK, #10

3шт.

30

129-17

NUT,Hex, #10 - 24

NUT - hex, No. 10

1шт.

31

129-37

NUT,#10-32

2шт.

32

223-38

FUSE,3 Amp, Type 3AG

- 3 amperes, 3 AG

1шт.
