Запчасти Case 780B (415C) - DECAL KIT, USED ON MODELS WITH BROWN AND TAN COLOR SCHEME (09) - CHASSIS/ATTACHMENTS

REF

INSTRUCTION

KIT - decal, Includes: Ref. 36 - 54 and Ref. 1 - 35 on Figure 415A

1шт.

36

321-6211

DECAL

loader lever, two spool

1шт.

37

321-6212

DECAL

loader lever, three spool

1шт.

38

D55216

PAD,2" x 9"

STRIP - nonskid, steps

1шт.

39

321-3863

DECAL

oil filter

1шт.

40

D80270

ANTI-SKID STRIP,635mm / 25 Inch

STRIP, ANTI-SKID, Operators compartment, side

2шт.

41

D87870

DECAL

reflector, red, rear

2шт.

42

321-6666

DECAL

Warning, hydraulic oil pressure

2шт.

43

D123941

DECAL

Extendahoe controls, upper

1шт.

44

D123940

DECAL

Extendahoe controls, lower

1шт.

45

D123945

DECAL

Extendahoe

2шт.

46

F45339

DECAL

Important, Wiper, Park, Run, if used

1шт.

47

L111358

DECAL

Cold Start

1шт.

48

321-5801

DECAL

Caution, windshield wiper position, if used

1шт.

49

D123978

DECAL

twin lever controls

1шт.

50

D123948

DECAL

Extendahoe pedal

1шт.

51

321-3596

DECAL

fan warning

2шт.

52

RESERVED

1шт.

53

321-4739

EMBLEM

Case, on grille

1шт.

54

131-431

PUSH-ON NUT,Self, Threading, 1/4"

push, attaches emblem to grille

2шт.

55

321-3055

DECAL

Warning, seat spring

1шт.

This Ref. is not included in the decal kit and must be ordered separately.

1шт.

56

L111356

DECAL

Boom Lock

1шт.

This Ref. is not included in the decal kit and must be ordered separately.

1шт.

57

RESERVED

1шт.

58

321-2654

DECAL

4-in-1 bucket indicator

1шт.

This Ref. is not included in the decal kit and must be ordered separately.

1шт.

59

321-4614

TAG

- Do not operate

1шт.

This Ref. is not included in the decal kit and must be ordered separately.

1шт.
