Запчасти Case 780B (030) - MANIFOLDS, 336BDT DIESEL ENGINE, INTAKE MANIFOLD (02) - ENGINE

1

A154149

MANIFOLD

intake (aluminum), Includes: Ref. 2 - 4

1шт.

2

L10283

PLUG

intake manifold heater hole

1шт.

3

A20916

MANIFOLD GASKET

heater hole plug

1шт.

4

221-1011

DRAIN PLUG,Sq Hd, 1/8"-27 NPTF

square head pipe, 1/8 inch PT

1шт.

5

A58662

MANIFOLD GASKET

intake manifold

4шт.

8

A59077

STUD

3/8 NC x 1-3/4 inch

8шт.

9

195-25

WASHER,3/8"

flat, 3/8 x 13/16 x 1/16 inch (10 x 21 x 2 mm)

8шт.

10

92-6

LOCK WASHER,3/8"

8шт.

11

25-166

NUT,3/8"-16, G5, Hvy

hex, 3/8 inch NC

8шт.

15

A61001

MANIFOLD

exhaust

1шт.

16

A58895

GASKET

exhaust manifold (metal faced)

4шт.

17

A59077

STUD

3/8 inch NC x 1-3/4 inch, exhaust manifold

8шт.

18

92-6

LOCK WASHER,3/8"

exhaust manifold 3/8"

8шт.

19

131-903

NUT,3/8"-16

hex Seez-Pruf, 3/8 inch NC, exhaust manifold

8шт.
