Артикул
Название
Примечание
Количество
1
D93913
VALVE
CONTROL VALVE ASSEMBLY - stabilizer, Cessna No. 39042-AAK, Includes: Refs. 2 - 18, order D124856 valve for service
1шт.
When replacing seat or plunger in D93913 and D123146 control valves, replace both N8451 seat and N8452 plunger at the same time.
1шт.
1
D123146
VALVE
CONTROL VALVE ASSEMBLY - stabilizer, Cessna No. 39042-AAL, Includes: Refs. 2 - 18, order D124856 valve for service
1шт.
When replacing seat or plunger in D93913 and D123146 control valves, replace both N8451 seat and N8452 plunger at the same time.
1шт.
1
DR124856
VALVE
CONTROL VALVE ASSEMBLY - stabilizer, remanufactured, component parts shown on this Figure do not apply to the remanufactured assembly, Includes: Ref. 2 - 18
1шт.
1
DC124856
CORE-VALVE HYD
RETURN NUMBER - use this part number to return the valve core for credit when using a remanufactured assembly, Includes: Ref. 2 - 18
1шт.
1
D124856
VALVE
CONTROL VALVE ASSEMBLY - stabilizer, new, Cessna No. 39042-AAQ, Includes: Refs. 2 - 18
1шт.
2
NSS
NOT SOLD SEPARAT
BODY - control valve
1шт.
3
NSS
NOT SOLD SEPARAT
SPOOL - control valve
2шт.
4
D56443
O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro
- spool
4шт.
5
D56439
BUSHING
- spool
2шт.
6
N6470
WASHER
- spring retainer
4шт.
7
D56909
BUSHING
SPACER - spring
2шт.
8
D56445
SPRING
- spool return
2шт.
9
A27020
RING
- retaining, washer
2шт.
10
F35196
CAP
- spool end
2шт.
11
D59653
PLUG
- spring retainer
2шт.
12
D56444
SPRING
- poppet
2шт.
13
D59654
VALVE
POPPET - control valve
2шт.
N8451
SEAT
ASSEMBLY - plunger, Includes: Ref. 14 and 15
2шт.
When replacing seat or plunger in D93913 and D123146 control valves, replace both N8451 seat and N8452 plunger at the same time.
1шт.
14
NSS
NOT SOLD SEPARAT
SEAT - plunger
1шт.
15
D48359
O-RING,0.103" Thk x 0.549" ID, -113, Cl 6, 90 Duro
- seat
1шт.
16
N8452
PLUNGER
- control valve
2шт.
When replacing seat or plunger in D93913 and D123146 control valves, replace both N8451 seat and N8452 plunger at the same time.
1шт.
17
D31410
O-RING,0.103" Thk x 0.674" ID, -115, Cl 6, 90 Duro
- plunger
2шт.
