Запчасти Case 780 (198) - TRANSMISSION, PARKING BRAKE (06) - POWER TRAIN

L41513

TRANSMISSION ASSEMBLY - complete, Includes: Ref. 1 - 14

1шт.

D55861

TRANSMISSION ASSEMBLY - complete, Includes: Ref. 1 - 14

1шт.

1

14-612

BOLT,Hex, 3/8" - 24 x 3/4", Gr 5, Full Thd

6шт.

2

92-6

LOCK WASHER,3/8"

6шт.

3

A17982

DRUM

- parking brake

1шт.

4

L33536

FLANGE

- output

1шт.

5

13-916

BOLT,Hex, 9/16" - 12 x 1", Gr 5

- hex, 9/16" - 12 NC x 1"

4шт.

6

193-33

LOCK WASHER,9/16"

WASHER - lock, internal tooth, 9/16"

4шт.

L33577

BRAKE

ASSEMBLY - parking, Includes: Ref. 7 - 14

1шт.

7

A18133

BRAKE SHOE

SHOE AND LINING ASSEMBLY - parking brake, Includes: Ref. 8 - 10

2шт.

8

NSS

NOT SOLD SEPARAT

RIVET -, Serial Range: lining-shoe

10шт.

See Figure 272 for parking brake controls.

1шт.

Part of lining and rivet Kit P/N A18136

1шт.

9

NSS

NOT SOLD SEPARAT

LINING - brake shoe

1шт.

See Figure 272 for parking brake controls.

1шт.

Part of lining and rivet Kit P/N A18136

1шт.

10

NSS

NOT SOLD SEPARAT

SHOE - parking brake

1шт.

11

A1834

SPRING - shoe return

2шт.

12

D60994

LEVER

- parking brake actuating

1шт.

13

L33578

PLATE ASSY.

BACKING PLATE - parking brake

1шт.

14

L33579

ROLLER

- lever

1шт.

A18136

KIT

- lining and rivet, includes two linings and 20 rivets to service the entire parking brake

1шт.

See Figure 272 for parking brake controls.

1шт.
