Запчасти Case 780 (540) - ALTITUDE COMPENSATING KIT, NON TURBO-CHARGED ENGINES BEFORE SN. 5500550 (09) - CHASSIS/ATTACHMENTS

D17113

KIT

- altitude compensating, Includes: Ref. 1 - 28

1шт.

1

218-5064

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

FITTING - male, straight, Incl. Ref. 2

1шт.

2

218-5008

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk, Fitting

1шт.

3

D56206

TUBE - to reservoir, used with model 300 air compressor

1шт.

See Figure 148 for correct tubes for machines with model 400 air compressor.

1шт.

4

D56207

TUBE - to oil cooler, front, used with model 300 air compressor

1шт.

See Figure 148 for correct tubes for machines with model 400 air compressor.

1шт.

5

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

- hex, 3/8" - 16 NC x 2"

2шт.

6

D40236

CLAMP

- tube

4шт.

7

D36040

BUSHING

SPACER - tube clamp

2шт.

8

195-25

WASHER,3/8"

- flat, 3/8"

2шт.

9

131-652

LOCK NUT,3/8"-16, GB

NUT - hex, self lock, 3/8" - 16 NC

2шт.

10

121-2087

STUD

- weld, 3/8" - 16 NC, Serial Range: welded-chassis

4шт.

11

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

- hex, 3/8" - 16 NC x 2", Front mounting bolts

4шт.

12

13-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

Rear mounting bolts Hex, 3/8"-16 x 1 3/4", G5

4шт.

13

D55806

PANEL - hood side, L.H.

1шт.

14

D82163

PANEL, SIDE

PANEL - hood side, R.H.

1шт.

15

D85936

HOOD

- engine, top

1шт.

Hinge is NSS. Must order entire top hood assembly.

1шт.

16

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

2шт.

17

195-25

WASHER,3/8"

- flat, 3/8"

6шт.

18

92-6

LOCK WASHER,3/8"

6шт.

19

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

4шт.

20

13-416

BOLT,Hex, 1/4" - 20 x 1", Gr 5

Upper to lower link Hex, 1/4"-20 x 1", G5

2шт.

21

195-18

WASHER,1/4"

- flat, 1/4"

2шт.

22

D56325

LINK - hood support, lower

1шт.

23

131-2

NUT,1/4"-20, GB

NUT - hex, lock, 1/4" - 20 NC

2шт.

24

141-2

CLEVIS PIN,1/4" x .770"

PIN - clevis, 1/4"

2шт.

25

132-5

COTTER PIN,1/16" x 1/2"

Pin, Split (Cotter), 1/16" x 1/2"

2шт.

26

D56329

STRIP - hood dampening

2шт.

27

195-18

WASHER,1/4"

- flat, #10

8шт.

28

D55965

CLIP - retaining, side panel

4шт.

A42987

KIT

- engine components, altitude compensating, see Figure 36 for parts list

1шт.

This kit is no longer a serviced item. Must order component parts on page 37 for service.

1шт.
