Запчасти Case 680CK (278) - G34462 MID-INLET SECTION (35) - HYDRAULIC SYSTEMS

1

G34462

AIR INTAKE TUBE

MANIFOLD ASSY. - mid-let section, Includes: Ref. 2 - 17

1шт.

2

NSS

NOT SOLD SEPARAT

MANIFOLD

1шт.

3

G34456

VALVE POPPET

POPPET - check valve

1шт.

4

G34458

SPRING,Compression, 5.08mm OD x 27.56mm L

- check valve (1-3/32" free length)

1шт.

5

G34457

PLUG

- check valve

1шт.

6

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

"O" RING - plug (3/4 x 15/16 x 3/32")

1шт.

G34465

LOCK VALVE

VALVE ASSY. - relief (2150 P.S.I.), Includes: Ref. 8 - 17

1шт.

8

NSS

NOT SOLD SEPARAT

BODY - relief valve

1шт.

9

D39717

O-RING,1.051" ID x 1.191" OD

"O" RING - body, upper (1-1/16 x 1-3/16 x 1/16")

1шт.

10

R15365

O-RING,0.989" ID x 1.129" OD x 0.07"

"O" RING - body, lower

1шт.

11

G34774

OIL SEAL

RING - lower body "O" ring back-up

1шт.

12

D39716

PLUG

CAP - relief valve

1шт.

13

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

"O" RING - cap (3/4 x 15/ 16 x 3/32")

1шт.

14

D51540

VALVE SPRING

SPRING - pressure (1-9/32" free length)

1шт.

15

D39712

SHIM

- pressure spring adj. (32 ga.)

1шт.

15

A55894

SHIM,.0209" Thk

Pressure spring adj. (25 ga.) .0209" Thk

1шт.

15

A55893

SHIM,.0418" Thk

Pressure spring adj. (19 ga.) .0418" Thk

1шт.

16

NSS

NOT SOLD SEPARAT

POPPET - relief valve

1шт.

17

D39714

RING

- poppet sealing (13/32 x 1/2 x 3/32")

1шт.
