Артикул
Название
Примечание
Количество
1
L26379
PUMP
- equipment hydraulic, Parts list Figure 234
1шт.
2
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
HHCS - 3/8" - 16 NC x 1-1/2"
4шт.
3
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
4
A16961
FLANGE
- split, 3/4"
2шт.
5
A7623
O-RING,0.139" Thk x 0.984" ID, -214, Cl 5, 75 Duro
SEAL - "O"ring
1шт.
6
L53121
TUBE,8, 7.5" L
- pump to backhoe valve, center inlet (At pump)
1шт.
7
221-655
PLUG,Hex Hd, 3/4"-14
- pipe, hex. head (3/4" NPT)
1шт.
8
D31796
HOSE
- pump to backhoe (29" long)
1шт.
9
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
1шт.
10
R14098
CLAMP,1 1/4", Insul, 5/16" Bolt
- hose
1шт.
11
L47867
BRACKET - hose clamp
1шт.
12
95-5
WASHER,3/8" x 7/8" x .083"
- standard wrot (5/16")
2шт.
13
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
2шт.
14
9635082
NUT,5/16" - 18, Gr 5
- hex. (5/16" - 18 NC)
2шт.
16
L54278
TUBE - pump to backhoe valve, center inlet (Intermediate) 0.75" OD x 66, 2" L
1шт.
17
L25930
CLAMP
- tube
2шт.
18
13-68
SCREW,Hex, 3/8" - 16 x 1/2", Gr 5
HHCS - 3/8" - 16 NC x 1/2"
2шт.
19
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
2шт.
20
L54280
TUBE,0.75" OD
- pump to backhoe valve, center inlet (Rear)
1шт.
21
49858
O-RING,0.103" Thk x 0.75" ID, -116, Cl 5, 75 Duro
- tube
1шт.
22
13-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
1шт.
23
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
1шт.
24
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
1шт.
25
L53654
HOSE - backhoe valve, center inlet (33-1/2" long)
1шт.
26
L55388
TUBE,0.75" OD
- backhoe valve, center inlet
1шт.
27
218-5118
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 1-5/16" - 12 Male ORB
- adjustable, 90 degree, Includes: Ref. 28
1шт.
28
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O"ring
1шт.
29
G34451
VALVE - hydraulic, backhoe control, Parts list Figure 272
1шт.
30
REF
INSTRUCTION
VALVE - loader control, See Figure 212 for proper valve
1шт.
31
L30446
FITTING
CONNECTOR - power beyond, Includes: Ref. 32 and 33
1шт.
32
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O"ring, connector (Large)
1шт.
33
L32680
RING
SEAL - "O"ring, connector (Small)
1шт.
34
L55420
HOSE
- loader valve to backhoe valve, end inlet (64" long)
1шт.
35
D25156
CLAMP
- hose
2шт.
37
13-414
BOLT,Hex, 1/4" - 20 x 7/8", Gr 5, Full Thd
1шт.
38
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
39
25-104
NUT,1/4"-20, G5
1шт.
40
L53653
HOSE ASSY.
HOSE - tube to backhoe valve, end inlet (41" long)
1шт.
41
L55386
TUBE,1" OD
- at backhoe valve, end inlet
1шт.
42
218-5110
ELBOW,90 Degree Elbow, 1-5/16" - 12 Male JIC x 1-5/16" - 12 Male ORB
adjustable, Incl. Ref. 43 90º, 1 5/16"-12, 37º x 1 5/16"-12, O-Ring
1шт.
43
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O"ring
1шт.
44
218-5116
ELBOW,90 Degree Elbow, 1-5/8" - 12 Male JIC x 1-5/16" - 12 Male ORB
Adjustable, Incl. Ref. 45 90º, 1 5/8"-12, 37º x 1 5/16"-12, O-Ring
1шт.
45
218-5010
O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro
SEAL - "O"ring
1шт.
46
L55384
TUBE,1.25" OD
- return, valve outlet to reservoir
1шт.
47
L16417
HOSE ASSY.
HOSE - return, backhoe valve to reservoir (52-1/2" long)
1шт.
48
13-628
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
1шт.
49
95-6
WASHER,3/8"
- plain () 3/8"
1шт.
50
L47541
BRACKET
- hose clamp support
1шт.
51
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
1шт.
52
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
1шт.
53
13-652
BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5
1шт.
54
D40471
CLAMP
- hose, upper
1шт.
55
G49622
SPACER,5/8" Tube x 1 7/16"
- hose clamp
1шт.
56
D40471
CLAMP
- hose, center
1шт.
57
R14192
CLAMP,2", Insul, 3/8" Bolt
- hose, lower
1шт.
58
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
1шт.
59
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
1шт.
60
D40471
CLAMP
- tube
1шт.
61
13-514
BOLT,Hex, 5/16" - 18 x 7/8", Gr 5
1шт.
62
95-5
WASHER,3/8" x 7/8" x .083"
- standard wrot (5/16")
1шт.
63
92-5
LOCK WASHER,5/16"
med. sect. 5/16"
1шт.
64
9635082
NUT,5/16" - 18, Gr 5
- hex. (5/16" - 18 NC)
1шт.
65
A14183
CLAMP - tube
1шт.
66
13-610
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd
1шт.
67
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
1шт.
68
L53576
TUBE,1.25" OD
- return, backhoe valve to reservoir
1шт.
69
L53566
HOSE ASSY.
HOSE - return, backhoe, Serial Range: valve-reservoir
1шт.
70
214-258
HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm
2шт.
71
REF
INSTRUCTION
TANK - hydraulic oil reservoir, See Figure 132 for complete chassis
1шт.
Выбрано товаров: 70
