Артикул
Название
Примечание
Количество
1
G32683
HYD TUBE,4.5" ID x 52.62" L
CYLINDER ASSY. - crowd, Includes: Ref. 2 - 21
1шт.
2
D44661
CYLINDER
TUBE ASSY. - cylinder, Includes: Ref. 3
1шт.
3
D38943
BUSHING,51.02mm ID x 63.5mm OD x 28.6mm L
- tube
2шт.
4
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
1шт.
5
D44659
ROD
ASSY. - piston, Includes: Ref. 6
1шт.
6
D38943
BUSHING,51.02mm ID x 63.5mm OD x 28.6mm L
- rod
1шт.
7
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, 1/8" P.T. str.
1шт.
8
187-1031
SELF-TAP SCREW,Pan, 0.164"-32 x 1/4"
SCREW - #8-32 x 1/4" self-tapping
1шт.
9
G32731
GLAND
- packing
1шт.
10
D95145
WIPER SEAL,54.79mm ID x 70.09mm OD x 7.91mm W
WIPER - piston rod
1шт.
Part of Seal Kit G32285
1шт.
11
G107924
SEAL,57.1mm ID x 69.9mm OD x 10.69mm Thk
SEAL - rod
1шт.
Part of Seal Kit G32285
1шт.
12
G32284
BACK-UP RING
- backup
1шт.
Part of Seal Kit G32285
1шт.
13
A23316
O-RING,0.139" Thk x 4.484" ID, -246, Cl 5, 75 Duro
"O" RING - 4-1/2 x 4-3/4 x 1/8"
1шт.
Part of Seal Kit G32285
1шт.
15
D46425
PISTON
- split, rod end
1шт.
16
D47210
BEARING WASHER,82.58mm ID x 113.97mm OD x 19mm Thk
RING - piston, vee seal
1шт.
17
D47205
PACKING
- piston, vee seal
2шт.
Part of Seal Kit G32285
1шт.
18
D46931
PISTON
- split, bolt end
1шт.
19
D38425
BOLT
- piston retaining (Self-locking)
1шт.
20
G32351
WASHER
- piston bolt, 1-11/32 x 2-1/2 x 9/64"
1шт.
21
221-11
PLUG,Sq Hd, 1/8"-27
- 1/8" P.T. sq. hd.
1шт.
G32285
SEAL
KIT - cylinder packing, Incl. Refs. 10, 11, 12, 13 and 17
1шт.
Выбрано товаров: 26
