Артикул
Название
Примечание
Количество
1
G32687
CYLINDER
ASSY. - bucket, Includes: Ref. 2 - 20
1шт.
2
D43351
CYLINDER
TUBE ASSY. - cylinder, Includes: Ref. 3
1шт.
3
D33047
BUSHING,44.68mm ID x 53.98mm OD x 22.23mm L
- tube
2шт.
4
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, 1/8" P.T. str.
2шт.
5
D38957
PISTON ROD
ROD ASSY. - piston, Includes: Ref. 6
1шт.
6
D31140
BUSHING,38.33mm ID x 47.63mm OD x 25.4mm L
- rod
2шт.
7
187-1031
SELF-TAP SCREW,Pan, 0.164"-32 x 1/4"
SCREW - #8 - 32 x 1/4" self-tapping
1шт.
8
D49500
GLAND
- packing
1шт.
9
D95145
WIPER SEAL,54.79mm ID x 70.09mm OD x 7.91mm W
WIPER - piston rod
1шт.
Part of Seal Kit G32697
1шт.
10
G107924
SEAL,57.1mm ID x 69.9mm OD x 10.69mm Thk
SEAL - rod
1шт.
Part of Seal Kit G32697
1шт.
11
G32176
BACK-UP RING,101.22mm ID x 107.32mm OD x 1.4mm Thk
1шт.
Part of Seal Kit G32697
1шт.
12
A27507
O-RING,0.139" Thk x 3.984" ID, -242, Cl 5, 75 Duro
"O" ring - 4 x 4-1/4 x 1/8"
1шт.
Part of Seal Kit G32697
1шт.
15
D49168
PISTON
- split, rod end
1шт.
16
D47209
BEARING,3.006" ID x 3.987" OD x 0.631"
RING - piston, vee seal
1шт.
17
D47204
PACKING,89.15mm ID x 100.86mm OD
- piston, vee seal
2шт.
Part of Seal Kit G32697
1шт.
18
D46930
PISTON
- split, bolt end
1шт.
19
28-2040
BOLT,Hex, 1-1/4" - 12 x 2-1/2", Gr 8
Piston retaining Hex, 1 1/4"-12 x 2 1/2", G8
1шт.
20
G32351
WASHER
- piston bolt, 1-11/32 x 2-1/2 x 9/64"
1шт.
G32697
SEAL
KIT - cylinder packing, Incl. Refs. 9, 10, 11, 12 and 17
1шт.
Выбрано товаров: 24
